DIAGNOSIS SYSTEM (BCM)
EXL-27
< SYSTEM DESCRIPTION >
C
D
E
F
G
H
I
J
K
M
A
B
EXL
N
O
P
HEADLAMP : CONSULT-III Function (BCM - HEAD LAMP)
INFOID:0000000006607769
DATA MONITOR
ACTIVE TEST
WORK SUPPORT
Monitor Item [Unit]
Description
IGN ON SW [On/Off]
Indicates condition of ignition switch ON position.
ACC ON SW [On/Off]
Indicates condition of ignition switch ACC position.
HI BEAM SW [On/Off]
Indicates condition of combination switch.
HEAD LAMP SW 1 [On/Off]
HEAD LAMP SW 2 [On/Off]
LIGHT SW 1ST [On/Off]
AUTO LIGHT SW [On/Off]
PASSING SW [On/Off]
FR FOG SW [On/Off]
DOOR SW-DR [On/Off]
Indicates condition of front door switch LH.
DOOR SW-AS [On/Off]
Indicates condition of front door switch RH.
DOOR SW-RR [On/Off]
Indicates condition of rear door switch RH.
DOOR SW-RL [On/Off]
Indicates condition of rear door switch LH.
TURN SIGNAL R [On/Off]
Indicates condition of combination switch.
TURN SIGNAL L [On/Off]
CARGO LAMP SW [ON/OFF]
Indicates condition of cargo lamp switch.
OPTICAL SENSOR [ON/OFF]
Indicates voltage signal from optical sensor.
Test Item
Description
TAIL LAMP
This test is able to check tail lamp operation [Off/On].
HEAD LAMP
This test is able to check head lamp operation [Off/Lo/Hi].
FR FOG LAMP
This test is able to check front fog lamp operation [Off/On].
CARGO LAMP
This test is able to check cargo lamp operation [Off/On].
CORNERING LAMP
This test is able to check turn signal lamp operation [Off/LH/RH].
Support Item
Setting
Description
BATTERY SAVER SET
Off
Exterior lamp battery saver function OFF.
On*
Exterior lamp battery saver function ON.
CUSTOM A/LIGHT SETTING
MODE4
Less sensitive setting than normal setting (Turns ON later than
normal operation).
MODE3
More sensitive setting than MODE 2 (Turns ON earlier than
MODE 2).
MODE2
More sensitive setting than normal setting (Turns ON earlier
than normal operation).
MODE1*
Normal.
