DLK-30 < DTC/CIRCUIT DIAGNOSIS > DOOR SWITCH 4. Check continuity between door switch connector B8 (Front LH), B108 (Front RH), B18 (Rear LH), B116 (Rear RH) terminal 2 and ground. Is the inspection result normal? YES >> GO TO 3 NO >> Repair or replace harness. 3. CHECK DOOR SWITCHES Check continuity between door switch terminal 2 and exposed metal of switch while pressing and releasing switch. Is the inspection result normal? YES >> Check door switch case ground condition. NO >> Replace door switch. 2 - 47 :Continuity should exist 2 - 12 :Continuity should exist 2 - 48 :Continuity should exist 2 - 13 :Continuity should exist 2 - Ground :Continuity should not exist LIIA1178E Terminals Condition Continuity Door switch (front and rear) 2 – Ground Released Yes Pressed No WIIA0644E |
