Nissan Titan A60. Manual - part 113

AV

SATELLITE RADIO TUNER

AV-277

< ECU DIAGNOSIS INFORMATION >

[PREMIUM WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

30

(W/L)

Ground

Communication signal
(CONT

→SAT)

Input

Ignition

switch

ON

When satellite radio mode
is selected

32

(Y)

Ground Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

36

(V)

Ground ACC power supply

Input

Ignition

switch

ACC

—

Battery voltage

37

(B)

—

Satellite antenna

Input

—

—

—

Terminal

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIA9301J

AV-278

< ECU DIAGNOSIS INFORMATION >

[PREMIUM WITH NAVIGATION]

DVD PLAYER

DVD PLAYER

Reference Value

INFOID:0000000006166627

PHYSICAL VALUES

ALNIA1128ZZ

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

1

(B)

2

(W)

DVD audio signal LH

Output

Ignition

switch

ON

With operation of the DVD
player

3

(R)

4

(G)

DVD audio signal RH

Output

Ignition

switch

ON

With DVD player operation

9

(L/W)

Ground Audio ON

Output

Ignition

switch

ON

With DVD player operation

Battery voltage

10

(BR)

Ground Illumination control

Input

Ignition

switch

ON

With lighting switch in 1st or
2nd position

Varies between 0 and Battery

voltage

11

(Y/L)

Ground

Family entertainment sys-
tem enable

Input

Ignition

switch

ON

With DVD player operation

Battery voltage

12

(R/L)

Ground Illumination power

Input

Ignition

switch

ON

With lighting switch in 1st or

2nd position

Battery voltage

15

(V)

Ground ACC power

Input

Ignition

switch

ACC or

ON

—

Battery voltage

16

(Y)

Ground Battery power

Input

—

—

Battery voltage

SKIB3609E

SKIB3609E

AV

DVD PLAYER

AV-279

< ECU DIAGNOSIS INFORMATION >

[PREMIUM WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

19

(B/W)

Ground Ground

—

Ignition

switch

ON

—

0V

21

(G/Y)

Ground Switch power

Output

Ignition
switch
ON

With DVD player operation

5V

22

(B)

Ground Ground

—

Ignition

switch

ON

—

0V

23

(B/W)

Ground VTR (+)

Output

Ignition

switch

ON

With DVD player operation

—

24

(L)

Ground VTR (-)

Output

Ignition

switch

ON

With DVD player operation

—

26

—

Shield

—

—

—

—

27

(B/Y)

Ground Ground

—

Ignition

switch

ON

—

0V

28

(Y)

—

Data receive

Input

—

—

—

29

(BR)

—

Data transmit

Output

—

—

—

31

(SB)

Ground Battery power

Output

—

—

Battery voltage

32

(BR)

Ground Battery power

Output

—

—

Battery voltage

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

AV-280

< ECU DIAGNOSIS INFORMATION >

[PREMIUM WITH NAVIGATION]

AUDIO AMP

AUDIO AMP

Reference Value

INFOID:0000000006166628

TERMINAL LAYOUT

PHYSICAL VALUES

AWNIA1623ZZ

Terminal

(wire color)

Item

Signal

input/

output

Condition

Reference value

(Approx.)

+

–

1

 (Y)

Ground

Battery

Input

–

–

Battery voltage

2

 (W)

18

(B)

Subwoofer

Output

Ignition

switch

ON

Receive audio sig-
nal

3

(BR/W)

19

(BR)

Subwoofer

Output

Ignition

switch

ON

Receive audio sig-
nal

4

 (B)

Ground

Ground

–

Ignition

switch

ON

–

–

9

(G/W)

Ground

Amp. ON signal

Input

Ignition

switch

ON

–

More than 6.5V

10

 (L/W)

26

(L/B)

Center speaker

Output

Ignition

switch

ON

Receive audio sig-
nal

SKIA0177E

SKIA0177E

SKIA0177E
