Nissan Titan A60. Manual - part 60

AV

AUDIO UNIT

AV-65

< ECU DIAGNOSIS INFORMATION >

[MID AUDIO]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

ECU DIAGNOSIS INFORMATION

AUDIO UNIT

Reference Value

INFOID:0000000006166476

TERMINAL LAYOUT

PHYSICAL VALUES

AWNIA1593ZZ

Terminal

 (Wire color)

Item

Signal

input/

output

Condition

Reference value

(Approx.)

+

–

2

(L/W)

1

(L/R)

Audio sound signal
front LH

Output

Ignition

switch

ON

Receive audio sig-
nal

4

(W/B)

3

(L/B)

Audio sound signal
front RH

Output

Ignition

switch

ON

Receive audio sig-
nal

6

(Y)

Ground

Battery power

Input

–

–

Battery voltage

7

(BR)

Ground

Illumination control
signal

Input

Ignition

switch

ON

Illumination control
switch is operated
by lighting switch in
1st position.

Changes between 0 and 12V

8

(R/L)

Ground

Illumination signal

Input

OFF

Lighting switch is in
1st position.

Battery voltage

Lighting switch is
OFF.

0V

10

(V)

Ground

ACC signal

Input

Ignition

switch

ON

–

Battery voltage

SKIA0177E

SKIA0177E

AV-66

< ECU DIAGNOSIS INFORMATION >

[MID AUDIO]

AUDIO UNIT

14

(SB)

13

(B/Y)

Audio sound signal
rear LH

Output

Ignition

switch

ON

Receive audio sig-
nal

16

(O/L)

15

(R/L)

Audio sound signal
rear RH

Output

Ignition

switch

ON

Receive audio sig-
nal

62

(G)

61

(R)

Tel audio sig

Input

Ignition

switch

ON

Bluetooth control

unit sends audio

signal

63

(Y)

–

Mute control

–

–

–

–

64

–

Shield

–

Ignition

switch

ON

–

0V

67 –

Shield

–

Ignition

switch

ON

–

0V

69

(R/G)

Ground

Remote control A

Output

Ignition

switch

ON

Audio unit ON

5V

70

(G/W)

Ground

Remote control B

Output

Ignition

switch

ON

Audio unit ON

5V

71

(Y/R)

Ground

Remote control
ground

–

–

–

0V

73

(W/R)

Ground

Vehicle speed sig-
nal (8-pulse)

Input

Ignition

switch

ON

When vehicle speed

is approx. 40 km/h

(25 mph)

Terminal

 (Wire color)

Item

Signal

input/

output

Condition

Reference value

(Approx.)

+

–

SKIA0177E

SKIA0177E

SKIB3609E

PKIA1935E

AV

AUDIO UNIT

AV-67

< ECU DIAGNOSIS INFORMATION >

[MID AUDIO]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

74

(W)

Ground

Auxiliary audio in-
put RH (+)

Input

Ignition

switch

ON

Receive audio sig-
nal (AUX input)

75

(R)

Ground

Auxiliary audio in-
put LH (+)

Input

Ignition

switch

ON

Receive audio sig-
nal (AUX input)

76

(B)

–

Shield

–

–

–

0V

Terminal

 (Wire color)

Item

Signal

input/

output

Condition

Reference value

(Approx.)

+

–

SKIA0177E

SKIA0177E

AV-68

< ECU DIAGNOSIS INFORMATION >

[MID AUDIO]

BLUETOOTH CONTROL UNIT

BLUETOOTH CONTROL UNIT

Reference Value

INFOID:0000000006706843

TERMINAL LAYOUT

PHYSICAL VALUES

AWNIA1628ZZ

Terminal

(wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

output

1

 (Y)

Ground Battery power

Input

–

–

Battery voltage

2

(V)

Ground ACC power

Input

Ignition

switch

ACC/ON

–

Battery voltage

3

(G/R)

Ground  IGN power

Input

Ignition

switch

ON/

START

–

Battery voltage

4

(B/W)

Ground Ground

–

Ignition

switch

ON

–

0V

6

–

Shield

–

–

–

–

7

 (B)

8

(R/L)

MIC in signal

Input

–

–

–

9

(G)

10

(R)

Audio out

Output

Ignition

switch

ACC/ON

Bluetooth control

unit sends audio

signal

11

(Y)

–

Mute control

–

–

–

–

12

(R)

14

(L)

Steering switch
signal A

Input

Ignition

switch

ON

Pressing



switch

 0V

Pressing

switch

0.75

Pressing VOL up
switch

2V

Except for above

5V

SKIB3609E
