SEAT BELT WARNING SYSTEM

SBC-11

< DTC/CIRCUIT DIAGNOSIS >

C

D

E

F

G

I

J

K

L

M

A

B

SBC

N

O

P

JRHWC1435GB

SBC-12

< DTC/CIRCUIT DIAGNOSIS >

SEAT BELT WARNING SYSTEM

JRHWC1436GB

SEAT BELT WARNING LAMP DOES NOT TURN OFF

SBC-13

< SYMPTOM DIAGNOSIS >

C

D

E

F

G

I

J

K

L

M

A

B

SBC

N

O

P

SYMPTOM DIAGNOSIS

SEAT BELT WARNING LAMP DOES NOT TURN OFF

Diagnosis Procedure

INFOID:0000000009949406

1.

CHECK SEAT BELT BUCKLE SWITCH (DRIVER SIDE)

Check seat belt buckle switch (driver side). Refer to

SBC-5, "DRIVER SIDE : Component Function Check"

Is the inspection result normal?

YES

>> GO TO 2.

NO

>> Repair or replace the malfunctioning parts.

2.

.CHECK SEAT BELT BUCKLE SWITCH (PASSENGER SIDE)

Check seat belt buckle switch (passenger side). Refer to

SBC-6, "PASSENGER SIDE : Component Function

Check"

NOTE:
Except for Mexico

Is the inspection result normal?

YES

>> GO TO 3.

NO

>> Repair or replace the malfunctioning parts.

3.

.CHECK SEAT BELT WARNING LAMP CIRCUIT

Check seat belt warning lamp circuit. Refer to

SBC-9, "Diagnosis Procedure"

Is the inspection result normal?

YES

>> GO TO 4.

NO

>> Repair or replace the malfunctioning parts.

4.

CONFIRM THE OPERATION

Confirm the operation again.
Is the inspection result normal?

YES

>> Check intermittent incident. Refer to

GI-40, "Intermittent Incident"

.

NO

>> GO TO 1.

SBC-14

< SYMPTOM DIAGNOSIS >

SEAT BELT WARNING LAMP DOES NOT TURN ON

SEAT BELT WARNING LAMP DOES NOT TURN ON

Diagnosis Procedure

INFOID:0000000009949407

1.

CHECK SELF-DIAGNOSIS RESULT

Perform “COMBINATION METER” self-diagnosis result. Refer to

MWI-30, "CONSULT Function (METER/

M&A)"

Is DTC detected?

YES

>> Repair or replace the malfunctioning parts.

NO

>> GO TO 2.

2.

CHECK POWER SUPPLY

Check that fuses are not blown.
Check ignition power supply of combination meter. Refer to

MWI-39, "COMBINATION METER : Diagnosis

Procedure"

Is the inspection result normal?

YES

>> GO TO 3.

NO

>> Repair or replace the malfunctioning parts.

3.

CHECK SEAT BELT BUCKLE SWITCH (DRIVER SIDE)

Check seat belt buckle switch (driver side). Refer to

SBC-5, "DRIVER SIDE : Component Function Check"

Is the inspection result normal?

YES

>> GO TO 4.

NO

>> Repair or replace the malfunctioning parts.

4.

.CHECK SEAT BELT BUCKLE SWITCH (PASSENGER SIDE)

Check seat belt buckle switch (passenger side). Refer to

SBC-6, "PASSENGER SIDE : Component Function

Check"

NOTE:
Except for Mexico

Is the inspection result normal?

YES

>> GO TO 5.

NO

>> Repair or replace the malfunctioning parts.

5.

.CHECK SEAT BELT WARNING LAMP CIRCUIT

Check seat belt warning lamp circuit. Refer to

SBC-9, "Diagnosis Procedure"

Is the inspection result normal?

YES

>> GO TO 6.

NO

>> Repair or replace the malfunctioning parts.

6.

CONFIRM THE OPERATION

Confirm the operation again.

Is the inspection result normal?

YES

>> Check intermittent incident. Refer to

GI-40, "Intermittent Incident"

.

NO

>> GO TO 1.
