LAN
CAN COMMUNICATION SYSTEM
LAN-25
< DTC/CIRCUIT DIAGNOSIS >
[CAN]
C
D
E
F
G
H
I
J
K
L
B
A
O
P
N
DTC/CIRCUIT DIAGNOSIS
CAN COMMUNICATION SYSTEM
Component Parts Location
INFOID:0000000009949491
1.
ABS actuator and electric unit (con-
trol unit) E36
2.
Combination meter M34
3.
EPS control unit M37
4.
IPDM E/R E13
5.
ECM E16
6.
TCM E18
7.
BCM
M65: Without Intelligent Key
M68: With Intelligent Key
8.
Data link connector M4
9.
Steering angle sensor M30
10. Air bag diagnosis sensor unit M59
JPMIA1465ZZ
