EXL-114

< ECU DIAGNOSIS INFORMATION >

BCM (BODY CONTROL MODULE)

93

(GR/W)

Ground

Intelligent Key warn-
ing buzzer

Output

Intelligent Key
warning buzzer

Sounding

0 V

Not sounding

12 V

96

(BR/W)

Ground

ACC relay control

Output

Ignition switch

OFF

0 V

ACC or ON

12 V

97

(L/R)

Ground

Starter relay control

Output

Ignition switch
ON

When selector lever is in
P or N position

Battery voltage

When selector lever is not
in P or N position

0 V

98

(BR)

Ground

Ignition relay (IPDM
E/R) control

Output

Ignition switch

OFF or ACC

12 V

ON

0 V

99

(W/R)

Ground

Ignition relay control

Output

Ignition switch

OFF or ACC

0 V

ON

12 V

100

(G)

Ground

Passenger door re-
quest switch

Input

Passenger door
request switch

ON (Pressed)

0 V

OFF (Not pressed)

12 V

102

(G)

Ground

Selector lever P/N
position

Input

Selector lever

P or N position

Battery voltage

Except P and N positions

0 V

103

(G/Y)

Ground

Front defroster
switch

Input

Ignition switch
ON

A/C mode defroster ON
position

0 V

Other than A/C mode de-
froster ON position

8.0 - 9.0 V

104

(Y/R)

Ground

CVT shift selector
(detention switch)
power supply

Output

Ignition switch ON

12 V

105

(B/O)

Ground

Stop lamp switch 2

Input

Ignition switch OFF

Battery voltage

106

(Y/B)

Ground

Blower fan motor re-
lay control

Output

Ignition switch

OFF or ACC

0 V

ON

12 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

JPMIA0589GB

BCM (BODY CONTROL MODULE)

EXL-115

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

M

A

B

EXL

N

O

P

WITH INTELLIGENT KEY : Wiring Diagram - BCM -

INFOID:0000000010249354

JRMWE7712GB

EXL-116

< ECU DIAGNOSIS INFORMATION >

BCM (BODY CONTROL MODULE)

JRMWE7713GB

BCM (BODY CONTROL MODULE)

EXL-117

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

M

A

B

EXL

N

O

P

JRMWE7714GB
