BCM (BODY CONTROL MODULE) WW-53 < ECU DIAGNOSIS INFORMATION > C D E F G H I J K M A B WW N O P SFT P -MET Selector lever in any position other than P Off Selector lever in P position On SFT N -MET Selector lever in any position other than N Off Selector lever in N position On ENGINE STATE Engine stopped Stop While the engine stalls Stall At engine cranking Crank Engine running Run S/L LOCK-IPDM NOTE: Off S/L UNLK-IPDM NOTE: Off S/L RELAY-REQ NOTE: Off VEH SPEED 1 While driving Equivalent to speed- ometer reading VEH SPEED 2 While driving Equivalent to speed- ometer reading DOOR STAT-DR Driver door is locked LOCK Wait with selective UNLOCK operation (5 seconds) READY Driver door is unlocked UNLOCK DOOR STAT-AS Passenger door is locked LOCK Wait with selective UNLOCK operation (5 seconds) READY Passenger door is unlocked UNLOCK ID OK FLAG Driver side door is open after ignition switch is turned OFF Reset Ignition switch ON Set PRMT ENG STRT The engine start is prohibited Reset The engine start is permitted Set PRMT RKE STRT NOTE: Reset RKE OPE COUN1 During the operation of the key Operation frequency of the key RKE OPE COUN2 NOTE: — CONFRM ID ALL The key ID that the key slot receives is not recognized by any key ID reg- Yet The key ID that the key slot receives is recognized by any key ID regis- Done CONFIRM ID4 The key ID that the key slot receives is not recognized by the fourth key ID Yet The key ID that the key slot receives is recognized by the fourth key ID reg- Done CONFIRM ID3 The key ID that the key slot receives is not recognized by the third key ID Yet The key ID that the key slot receives is recognized by the third key ID reg- Done Monitor Item Condition Value/Status |
