Nissan Cube. Manual - part 1022





WCS

BCM (BODY CONTROL MODULE)

WCS-91

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

19

(BR)

Ground

Remote keyless en-
try receiver power
supply

Input

Ignition switch
OFF

Insert mechanical key into
ignition key cylinder

0 V

Remove mechanical key
from ignition key cylinder
(Any door opened)

5 V

Remove mechanical key
from ignition key cylinder
(Any door closed)

20

(G/Y)

Ground

Remote keyless en-
try receiver commu-
nication

Input

Ignition switch
OFF

Insert mechanical key into
ignition key cylinder

0 V

Waiting

Signal receiving

21

(P/L)

Ground

NATS antenna amp.

Input/

Output

Just after inserting ignition key in key cylinder

Pointer of tester should move

Other than above

0 V

23

(R/Y)

Ground

Security indicator

Input

Security indica-
tor

ON

0 V

Blinking (Ignition switch
OFF)

11.3 V

OFF

12 V

25

(LG)

Ground

NATS antenna amp.

Input/

Output

Just after inserting ignition key in key cylinder

Pointer of tester should move

Other than above

0 V

26

(GR)

Ground

Thermo control amp.

Input

Ignition switch ON

0 V

Evaporator is extremely low temperature

12 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

JPMIA0338JP

PIIB7728J

PIIB7729J

JPMIA0014GB

WCS-92

< ECU DIAGNOSIS INFORMATION >

BCM (BODY CONTROL MODULE)

27

(Y/G)

Ground

A/C switch

Input

A/C switch

OFF

1.0 - 1.5 V

ON

0 V

28

(G/W)

Ground

Blower fan switch

Input

Fan switch

Blower fan switch OFF

7.0 - 8.0 V

Blower fan switch ON

0 V

29

(L/W)

Ground

Hazard switch

Input

Hazard switch

OFF

Battery voltage

ON

0 V

31

(G/Y)

Ground

Front defroster
switch

Input

Ignition switch
ON

A/C mode defroster ON
position

0 V

Other than A/C mode de-
froster ON position

8.0 - 9.0 V

32

(LG)

Ground

Combination switch
OUTPUT 5

Output

Combination
switch

All switch OFF
(Wiper intermittent dial 4)

7.0 - 8.0 V

Rear wiper switch ON
(Wiper intermittent dial 4)

1.0 V

Any of the condition below
with all switch OFF
• Wiper intermittent dial 1
• Wiper intermittent dial 2
• Wiper intermittent dial 6
• Wiper intermittent dial 7

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

JPMIA0012GB

PKIB4960J

JPMIA0589GB

PKIB4960J

PKIB4956J

WCS

BCM (BODY CONTROL MODULE)

WCS-93

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

33

(Y/L)

Ground

Combination switch
OUTPUT 4

Output

Combination
switch

All switch OFF
(Wiper intermittent dial 4)

7.0 - 8.0 V

Lighting switch 1ST
(Wiper intermittent dial 4)

1.2 V

Rear wiper switch INT
(Wiper intermittent dial 4)

Any of the condition below
with all switch OFF
• Wiper intermittent dial 1
• Wiper intermittent dial 5
• Wiper intermittent dial 6

34

(W)

Ground

Combination switch
OUTPUT 3

Output

Combination
switch

All switch OFF
(Wiper intermittent dial 4)

7.0 - 8.0 V

Lighting switch 2ND
(Wiper intermittent dial 4)

1.2 V

Lighting switch HI
(Wiper intermittent dial 4)

Rear washer switch ON
(Wiper intermittent dial 4)

Any of the condition below
with all switch OFF
• Wiper intermittent dial 1
• Wiper intermittent dial 2
• Wiper intermittent dial 3

35

(R/L)

Ground

Combination switch
OUTPUT 2

Output

Combination
switch
(Wiper intermit-
tent dial 4)

All switch OFF

7.0 - 8.0 V

Lighting switch 2ND

1.2 V

Lighting switch PASS

Front wiper switch INT

Front wiper switch HI

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

PKIB4960J

PKIB4958J

PKIB4960J

PKIB4958J

PKIB4960J

PKIB4958J

WCS-94

< ECU DIAGNOSIS INFORMATION >

BCM (BODY CONTROL MODULE)

36

(L/O)

Ground

Combination switch
OUTPUT 1

Output

Combination
switch
(Wiper intermit-
tent dial 4)

All switch OFF

7.0 - 8.0 V

Turn signal switch RH

1.2 V

Turn signal switch LH

Front wiper switch LO
(Front wiper switch MIST)

Front washer switch ON

37

(R/W)

Ground

Key switch

Input

Insert mechanical key into ignition key cylin-
der

Battery voltage

Remove mechanical key from ignition key
cylinder

0 V

38

(O)

Ground

Ignition switch ON

Input

Ignition switch OFF or ACC

0 V

Ignition switch ON

Battery voltage

39

(L)

Ground

CAN-H

Input/

Output

40

(P)

Ground

CAN-L

Input/

Output

43

(W)

Ground

Back door switch

Input

Back door
switch

OFF (When back door
closed)

7.0 - 8.0 V

ON (When back door
opened)

0 V

44

(LG)

Ground

Rear wiper stop po-
sition

Input

Ignition switch
ON

Rear wiper stop position

12 V

Any position other than
rear wiper stop position

0 V

45

(GR)

Ground

Door lock and unlock
switch LOCK

Input

Door lock and
unlock switch

NEUTRAL position

1.0 - 1.5 V

LOCK position

0 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

PKIB4960J

PKIB4958J

PKIB4960J

JPMIA0012GB
