NAVI CONTROL UNIT

AV-89

< ECU DIAGNOSIS INFORMATION >

[AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

43

(G/O)

Ground

Camera power supply

Output

Ignition

switch

ON

At rear view camera image
is displayed.

6.0 V

Except for above.

0 V

44

(G/R)

Ground

Camera ground

—

Ignition

switch

ON

—

0  V

45

(G)

—

USB ground

—

—

—

—

46

(R)

—

USB  D

−

 signal

Input/

Output

—

—

—

47

(L)

—

USB D+ signal

Input/

Output

—

—

—

48

(W)

—

V BUS signal

Output

—

—

—

49

(W)

—

AUX sound signal LH

Input

—

—

—

50

(G)

—

AUX sound signal RH

Input

—

—

—

51

(R)

—

AUX sound signal ground

—

—

—

—

53

—

Shield

—

—

—

—

54

Ground

GPS antenna signal

Input

ON

Not connected to GPS an-
tenna connector.

5.0 V

55

—

Shield

—

—

—

—

70

Ground

Antenna amp. ON signal

Output

Ignition

switch

ON

—

12.0 V

71

—

AM–FM main

Input

—

—

—

73

—

Satellite radio antenna sig-
nal

Input

—

—

—

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

AV-90

< ECU DIAGNOSIS INFORMATION >

[AUDIO WITH NAVIGATION]

TEL ADAPTER UNIT

TEL ADAPTER UNIT

Reference Value

INFOID:0000000009949611

TERMINAL LAYOUT

PHYSICAL VALUES

JPNIA0011ZZ

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

1

(R)

Ground

Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

2

(L)

Ground

ACC power supply

Input

Ignition

switch

ACC

—

Battery voltage

3

(LG)

Ground

Ignition signal

Input

Ignition

switch

ON

—

Battery voltage

4

(B)

Ground

Ground

—

Ignition

switch

ON

—

0  V

7

(L)

8

Microphone signal

Input

Ignition

switch

ON

Give a voice.

9

(BR)

10

(Y)

Sound signal
(TEL voice, voice guid-
ance)

Output

Ignition

switch

ON

During voice guide output

with the

 switch

pressed.

20

(B)

Ground

Control signal

—

Ignition

switch

ON

—

0  V

21

(B)

Ground

Control signal

—

Ignition

switch

ON

—

0  V

SKIB3609E

SKIB3609E

AV

TEL ADAPTER UNIT

AV-91

< ECU DIAGNOSIS INFORMATION >

[AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

24

(B)

Ground

Control signal

—

Ignition

switch

ON

—

0  V

27

(B)

Ground

Control signal

—

Ignition

switch

ON

—

0  V

28

(O)

Ground

Vehicle speed signal
(2-pulse)

Input

Ignition

switch

ON

When vehicle speed is ap-
prox. 40 km/h (25 MPH)

NOTE:
The maximum voltage varies de-
pending on the specification
(destination unit).

29

(R)

Ground

Microphone power supply

Output

Ignition

switch

ON

—

5.0  V

33

—

TEL antenna signal

Input

—

Not connected to TEL an-
tenna connector.

5.0 V

34

—

Shield

—

—

—

—

35

(SB)

—

AV communication signal
(H)

Input/

Output

—

—

—

36

(LG)

—

AV communication signal
(L)

Input/

Output

—

—

—

39

(Y/R)

—

Data line

—

—

—

—

40

(Y/R)

—

Data line

—

—

—

—

41

(SB)

—

Data line

—

—

—

—

42

(SB)

—

Data line

—

—

—

—

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

JSNIA0015GB

AV-92

< WIRING DIAGRAM >

[AUDIO WITH NAVIGATION]

AUDIO WITH NAVIGATION

WIRING DIAGRAM

AUDIO WITH NAVIGATION

Wiring Diagram

INFOID:0000000009949612

JRNWD0578GB
