BCS-101
< ECU DIAGNOSIS INFORMATION >
[WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
K
L
B
A
O
P
N
10
(G)
Ground
Rear defogger sw
signal
Input
Rear window
defogger switch
OFF
Battery voltage
ON
0 V
11
(L)
Ground ACC switch signal
Input
Ignition switch
OFF
0 V
ACC or ON
Battery voltage
12
(GR)
Ground
Central door lock sw
signal
Input
Door lock and
unlock switch
N position
1.0 - 1.5 V
LOCK position
0 V
13
(BR)
Ground
Central door unlock
sw signal
Input
Door lock and
unlock switch
N position
1.0 - 1.5 V
UNLOCK position
0 V
18
(V)
Ground Keyless gnd signal
Input
Ignition switch ON
0 V
19
(LG)
Ground
Keyless tuner power
supply
Input
Ignition switch
OFF
Key inserted into ignition
key cylinder
0 V
Key removed from ignition
key cylinder
(Any door open)
5 V
Key removed from ignition
key cylinder
(Any door closed)
Terminal No.
(Wire color)
Description
Condition
Value
(Approx.)
Signal name
Input/
Output
+
−
