EXL-16 < SYSTEM DESCRIPTION > DIAGNOSIS SYSTEM (BCM) ACTIVE TEST WORK SUPPORT * : Initial setting Monitor Item [Unit] Description REQ SW -DR [On/Off] Indicates condition of door request switch LH. REQ SW -AS [On/Off] Indicates condition of door request switch RH. PUSH SW [On/Off] Indicates condition of push-button ignition switch. TURN SIGNAL R [On/Off] Indicates condition of turn signal function of combination switch. TURN SIGNAL L [On/Off] HAZARD SW [On/Off] Indicates condition of hazard switch. RKE-LOCK [On/Off] Indicates condition of lock signal from Intelligent Key. RKE-UNLOCK [On/Off] Indicates condition of unlock signal from Intelligent Key. Test Item Description FLASHER This test is able to check turn signal lamp operation [Off/LH/RH]. Support Item Setting Description HAZARD ANSWER BACK Lock/Unlock* Hazard warning lamp activation when doors are locked or unlocked with Unlock Only Hazard warning lamp activation when doors are unlocked with Intelligent Lock Only Hazard warning lamp activation when doors are locked with Intelligent Off No hazard warning lamp activation when doors are locked or unlocked |
