SERVICE DATA AND SPECIFICATIONS (SDS) EC-339 < SERVICE DATA AND SPECIFICATIONS (SDS) [HR16DE] C D E F G H I J K L M A EC N P O SERVICE DATA AND SPECIFICATIONS (SDS) SERVICE DATA AND SPECIFICATIONS (SDS) Idle Speed INFOID:0000000009022694 *: Under the following conditions Ignition Timing INFOID:0000000009022695 *: Under the following conditions Calculated Load Value INFOID:0000000009022696 Mass Air Flow Sensor INFOID:0000000009022697 *: Engine is warmed up to normal operating temperature and running under no load. Transmission Condition Specification CVT No load* (in P or N position) 700 ± 50 rpm M/T No load* (in Neutral position) 650 ± 50 rpm Transmission Condition Specification CVT No load* (in P or N position) 11 ± 2°BTDC M/T No load* (in Neutral position) 10 ± 2°BTDC Condition Specification (Using CONSULT or GST) At idle 10 – 35% At 2,500 rpm 10 – 35% Supply voltage Battery voltage (11 – 14 V) Output voltage at idle 0.8 – 1.3 V* Mass air flow (Using CONSULT or GST) 0.8 – 4.0 g/s at idle* 2.0 – 10.0 g/s at 2,500 rpm* |
