BRM-1

BODY EXTERIOR, DOORS, ROOF & VEHICLE SECURITY

C

D

E

F

G

H

I

J

L

M

SECTION

BRM

A

B

BRM

N

O

P

CONTENTS

BODY REPAIR

VEHICLE INFORMATION .............................

2

BODY EXTERIOR PAINT COLOR  .....................

2

Body Exterior Paint Color .......................................

2

PRECAUTION ...............................................

3

PRECAUTIONS ...................................................

3

Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ...................................................................

3

SERVICE DATA AND SPECIFICATIONS
(SDS) .............................................................

4

BODY ALIGNMENT  ...........................................

4

Body Center Marks .................................................

4

Description ................................................................

5

Engine Compartment ...............................................

5

Underbody ................................................................

7

Passenger Compartment ........................................

10

Rear End Panel  .......................................................

11

BRM-2

< VEHICLE INFORMATION >

BODY EXTERIOR PAINT COLOR

VEHICLE INFORMATION

BODY EXTERIOR PAINT COLOR

Body Exterior Paint Color

INFOID:0000000009654082

M = Metallic, 2S = Solid and Clear, 3P = 3-Stage pearl, t = Primerless Diamond Clear coat.

AWKIA2519ZZ

Component

Color code

B17

FAK

QAC

KH3

K23

K36

NAC

RBE

Description

Blue

Green

White

Black

Silver

Gray

Red

Blue

Paint type

M

M

3P

2S

M

M

M

M

Hard  clear  coat

t

t

t

t

t

t

t

t

1

Door outside handles

Body color

B17

FAK

QAC

KH3

K23

K36

NAC

RBE

2

Fuel filler lid

Body color

B17

FAK

QAC

KH3

K23

   K36

NAC

RBE

3

Back door outer finisher Body color

B17

FAK

QAC

KH3

K23

K36

NAC

RBE

4

Rear bumper fascia

Body color

B17

FAK

QAC

KH3

K23

   K36

NAC

RBE

5

Door mirror

Body color

B17

FAK

QAC

KH3

K23

   K36

NAC

RBE

Black

KH3

KH3

KH3

KH3

KH3

   KH3

KH3

KH3

6

Front bumper fascia

Body color

B17

FAK

QAC

KH3

K23

   K36

NAC

RBE

7

Front grille

Black

KH3

KH3

KH3

KH3

KH3

KH3

KH3

KH3

PRECAUTIONS

BRM-3

< PRECAUTION >

C

D

E

F

G

H

I

J

L

M

A

B

BRM

N

O

P

PRECAUTION

PRECAUTIONS

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"

INFOID:0000000009654083

The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along

with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain

types of collision. Information necessary to service the system safely is included in the SR and SB section of

this Service Manual.

WARNING:

• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in

the event of a collision which would result in air bag inflation, all maintenance must be performed by

an authorized NISSAN/INFINITI dealer.

• Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal

injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag

Module, see the SR section.

• Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this

Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or har-

ness connectors.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

WARNING:

• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-

tion ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a

hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing

serious injury.

• When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the

battery and wait at least three minutes before performing any service.

BRM-4

< SERVICE DATA AND SPECIFICATIONS (SDS)

BODY ALIGNMENT

SERVICE DATA AND SPECIFICATIONS (SDS)

BODY ALIGNMENT

Body Center Marks

INFOID:0000000009654084

A mark has been placed on each part of the body to indicate the vehicle center. When repairing parts dam-

aged by an accident which might affect the vehicle frame (members, pillars, etc.), more accurate and effective

repair will be possible by using these marks together with body alignment specifications.

Front

Point

Portion

Mark

A

Cowl top extension

Hole

B

 Front roof position mark for alignment

Raised dimple

C

Rear roof position mark for alignment

Raised dimple

D

 Rear panel upper

Cut out

AWKIA2546ZZ
