Nissan Rogue. Manual - part 124





BCS-102

< ECU DIAGNOSIS INFORMATION >

[WITHOUT INTELLIGENT KEY SYSTEM]

BCM

38

(V)

Ground

Combination switch output
1

Output

Combination
switch
(Wiper inter-
mittent dial 1)

OFF

7.0 – 8.0V

HI BEAM

1.2V

PASSING

FR FOG

39

(W)

Ground

Combination switch output
2

Output

Combination
switch
(Wiper inter-
mittent dial 4)

OFF

7.0 – 8.0V

INT VOLUME 1

1.2V

HEADLAMP

TAIL LAMP

40

(SB)

Ground

Main power window and
door lock/unlock switch un-
lock signal

Input

Main power
window and
door lock/un-
lock switch
(door lock/un-
lock switch)

Unlock

Battery voltage

Lock

0V

50

(W)

Ground Right rear door switch

Input

Rear door
switch RH

OFF (door closed)

11.8V

ON (door open)

0V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

(+)

(-)

PKIB4960J

PKIB4958J

PKIB4960J

PKIB4958J

JPMIA0011GB

BCS

BCM

BCS-103

< ECU DIAGNOSIS INFORMATION >

[WITHOUT INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

51

(LG)

Ground Back door switch

Input

Back door
lock assem-
bly (door ajar
switch)

OFF (door closed)

11.8V

ON (door open)

0V

52

(R)

Ground Left rear door switch

Input

Rear door
switch LH

OFF (door closed)

11.8V

ON (door open)

0V

53

(SB)

Ground Passenger door switch

Input

Front door
switch RH

OFF (door closed)

11.8 V

ON (door open)

0V

55

(LA/G)

Ground Rear wiper autostop switch

Input

Ignition
switch ON

Rear wiper stop posi-
tion

Battery voltage

Any position other
than rear wiper stop

0V

56

(Y)

Ground Back door open switch

Input

Back door
opener switch

Switch released

Battery voltage

Switch pressed

0V

57

(SB)

Ground Driver door switch

Input

Front door
switch LH

OFF (door closed)

11.8V

ON (door open)

0V

60

(L)

Ground CAN high

Input/

Output

79

(LA/W)

Ground

High-mounted stop lamp
output

Output

Brake pedal

Released

0V

Depressed

Battery voltage

80

(P)

Ground CAN low

Input/

Output

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

(+)

(-)

JPMIA0011GB

JPMIA0011GB

JPMIA0011GB

JPMIA0011GB

BCS-104

< ECU DIAGNOSIS INFORMATION >

[WITHOUT INTELLIGENT KEY SYSTEM]

BCM

81

(L)

Ground Key switch signal

Input

Ignition
switch

Ignition key inserted
into ignition key cylin-
der

Battery voltage

Ignition key removed
from ignition key cyl-
inder

0 V

82

(LA/R)

Ground Ignition switch start signal

Input

Ignition
switch

OFF

0 V

START

Battery voltage

84

(BR)

Ground Combination switch input 2

Input

Combination
switch
(Wiper inter-
mittent dial 1)

OFF

0V

HI BEAM

1.0V

RR WASHER

FR WIPER HI

INT VOLUME 3

85

(SB)

Ground Combination switch input 1

Input

Combination
switch
(Wiper inter-
mittent dial 1)

OFF

0V

INT VOLUME 1

1.0V

FR WASHER

FR WIPER LOW

INT VOLUME 2

86

(P)

Ground Combination switch input 3

Input

Combination
switch
(Wiper inter-
mittent dial 1)

OFF

0V

PASSING

1.0V

HEADLAMP

FR WIPER INT

RR WIPER INT

87

(BG)

Ground Combination switch input 4

Input

Combination
switch
(Wiper inter-
mittent dial 1)

OFF

0V

TURN LH

1.0V

RR WIPER ON

92

(BR)

Ground

Front door lock assembly
LH key cylinder switch lock
signal

Input

Key cylinder
switch

OFF (neutral)

Battery voltage

ON (lock)

0V

93

(P)

Ground

Front door lock assembly
LH key cylinder switch un-
lock signal

Input

Key cylinder
switch

OFF (neutral)

Battery voltage

ON (unlock)

0V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

(+)

(-)

PKIB4958J

PKIB4958J

PKIB4958J

PKIB4958J

BCS

BCM

BCS-105

< ECU DIAGNOSIS INFORMATION >

[WITHOUT INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

94

(G)

Ground

CVT shift selector park po-
sition switch signal

Input

Selector lever

P position

0V

Except P position

Battery voltage

95

(V)

Ground Shorting input

Input

Ignition
switch

OFF

Battery voltage

104

(R)

Ground

Front door lock assembly
LH knob switch unlock sig-
nal

Input

Door lock
knob

OFF (lock)

Battery voltage

ON (unlock)

0V

105

(Y)

Ground Ignition switch ON signal

Input

Ignition
switch

OFF

0 V

ON

Battery voltage

106
(W)

Ground

Audio unit/AV control unit
accessory power supply

Input

Ignition
switch

ON

Battery voltage

109

(P)

Ground

Immobilizer one way com-
munication (clock) signal

Input/

Output

Ignition
switch ON

While waiting

Ignition switch ON: pointer of

tester should move.

113

(LG)

Ground

Immobilizer two way com-
munication signal

Input/

Output

Ignition
switch ON

While waiting

Ignition switch ON: pointer of

tester should move.

125

(LG)

Ground Stop lamp switch signal

Input

Brake pedal

Released

0V

Depressed

Battery voltage

126
(W)

Ground

Brake pedal position switch
signal

Input

Brake pedal

Released

0V

Depressed

Battery voltage

135

(BR)

Ground

Front combination lamp LH
turn signal lamp output

Output

Ignition
switch ON

Turn signal switch
OFF

0V

Turn signal switch LH

6.5 V

136

(GR)

Ground

Front combination lamp RH
turn signal lamp output

Output

Ignition
switch ON

Turn signal switch
OFF

0V

Turn signal switch RH

6.5 V

139

(G)

Ground Starter cut relay control

Output

Ignition
switch

OFF

Battery voltage

ON

0V

145

(LA/V)

Ground

Back door lock assembly
opener motor open

Output

Back door
opener switch
pressed

Open (motor activat-
ed)

Battery voltage

Back door
opener switch
released

Closed (motor not ac-
tivated)

0V

147

(LA/R)

Ground Rear wiper output

Output

Rear wiper

OFF

0V

ON

Battery voltage

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

(+)

(-)

PKID0926E

PKID0926E
