SUNSHADE
RF-169
< REMOVAL AND INSTALLATION >
[WITH DUAL PANEL SUNROOF]
C
D
E
F
G
H
I
J
L
M
A
B
RF
N
O
P
3. Using a suitable tool, wind the double-D tang end 20 turns counter-clockwise (when viewed from the end).
4. Insert the double-d tang end into the slot and lock it into the carrier.
5. Position the sunshade carrier assembly and install the bolts.
6. Position the center brackets (LH/RH) and install the bolts and nuts.
7. Install the side curtain air bag module bolts.
8. Install the headliner. Refer to
INT-33, "Removal and Installation"
.
