EXL-318
< REMOVAL AND INSTALLATION >
[HALOGEN TYPE]
FRONT COMBINATION LAMP
REMOVAL AND INSTALLATION
FRONT COMBINATION LAMP
Exploded View
INFOID:0000000009465387
Removal and Installation
INFOID:0000000009465388
FRONT COMBINATION LAMP
Removal
1. Remove the front bumper fascia. Refer to
EXT-16, "Removal and Installation"
.
2. Remove the front combination lamp bolts.
3. Remove the harness clips from the front combination lamp assembly.
4. Pull out the front combination lamp toward the front of vehicle.
5. Disconnect the harness connectors from the front combination lamp and remove.
Installation
Installation is in the reverse order of removal.
NOTE:
After installation, perform headlamp aiming adjustment. Refer to
EXL-315, "Aiming Adjustment Procedure"
.
HALOGEN BULB (LOW BEAM)
Removal
WARNING:
Do not touch bulb with your hand while it is on or right after being turned off, a burn injury may result.
CAUTION:
• After installing the bulb, install the plastic cover and the bulb socket securely for watertightness.
• Do not touch bulb glass with your hand or keep other grease and oily substances away from bulb
glass.
• Do not leave bulb out of lamp reflector for a long time because dust, moisture smoke, etc. may affect
the performance of lamp. When replacing bulb, be sure to replace it with new one.
1. Remove the front combination lamp. Refer to
EXL-318, "Removal and Installation"
.
2. Rotate the bulb socket counterclockwise and unlock from the front combination lamp.
3. Remove the bulb from the bulb socket
Installation
1.
Front combination lamp
ALLIA0897ZZ
