BCM (BODY CONTROL MODULE)

DEF-41

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

M

A

B

DEF

N

O

P

Fail Safe

INFOID:0000000010065036

140

(BR)

Ground

Engine switch (push
switch)

Input

Engine switch
(push switch)

Pressed

0V

Not pressed

Battery voltage

141

(BR)

Ground

Trunk opener request
switch

Input

Trunk opener re-
quest switch

ON (pressed)

0V

OFF (not pressed)

1.0V

144

(GR)

Ground

Request switch buzz-
er

Output

Request switch
buzzer

Sounding

0V

Not sounding

Battery voltage

147

(L/R)

Ground

Trunk lid opener
switch

Input

Trunk lid opener
switch

Pressed

0V

Not pressed

Battery voltage

148

(R/W)

Ground Rear door RH switch

Input

Rear door RH
switch

OFF (when rear door RH
closes)

11.8V

ON (when rear door RH
opens)

0V

149

(R/B)

Ground Rear door LH switch

Input

Rear door LH
switch

OFF (when rear door LH
closes)

11.8V

ON (when rear door LH
opens)

0V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

(+)

(-)

JPMIA0016GB

JPMIA0011GB

JPMIA0011GB

Display contents of CONSULT

Fail-safe

Cancellation

B2190: NATS ANTENNA AMP

Inhibit engine cranking

Erase DTC

B2191: DIFFERENCE OF KEY

Inhibit engine cranking

Erase DTC

B2192: ID DISCORD BCM-ECM

Inhibit engine cranking

Erase DTC

B2193: CHAIN OF BCM-ECM

Inhibit engine cranking

Erase DTC

B2195: ANTI-SCANNING

Inhibit engine cranking

Erase DTC

B2560: STARTER CONT RELAY

Inhibit engine cranking

500 ms after the following CAN signal communication status has
become consistent
• Starter control relay signal
• Starter relay status signal

DEF-42

< ECU DIAGNOSIS INFORMATION >

BCM (BODY CONTROL MODULE)

DTC Inspection Priority Chart

INFOID:0000000010065037

If some DTCs are displayed at the same time, perform inspections one by one based on the following priority

chart.

B2562: LO VOLTAGE

Inhibit engine cranking

100 ms after the power supply voltage increases to more than 8.8 V

B2608: STARTER RELAY

Inhibit engine cranking

500 ms after the following signal communication status becomes
consistent
• Starter motor relay control signal
• Starter relay status signal (CAN)

B260A: IGNITION RELAY

Inhibit engine cranking

500 ms after the following conditions are fulfilled
• IGN relay (IPDM E/R) control signal: OFF (Battery voltage)
• Ignition ON signal (CAN to IPDM E/R): OFF (Request signal)
• Ignition ON signal (CAN from IPDM E/R): OFF (Condition signal)

B260F: ENG STATE SIG LOST

Maintains the power supply
position attained at the time
of DTC detection

When any of the following conditions is fulfilled
• Power position changes to ACC
• Receives engine status signal (CAN)

B2617: STARTER RELAY CIRC

Inhibit engine cranking

1 second after the starter motor relay control inside BCM becomes
normal

B2618: BCM

Inhibit engine cranking

1 second after the ignition relay (IPDM E/R) control inside BCM be-
comes normal

B26E1: ENG STATE NO RECIV

Inhibit engine cranking

When any of the following conditions are fulfilled
• Power position changes to ACC
• Receives engine status signal (CAN)

Display contents of CONSULT

Fail-safe

Cancellation

Priority

DTC

1

• B2562: LO VOLTAGE

2

• U1000: CAN COMM CIRCUIT
• U1010: CONTROL UNIT (CAN)

3

• B2190: NATS ANTENNA AMP
• B2191: DIFFERENCE OF KEY
• B2192: ID DISCORD BCM-ECM
• B2193: CHAIN OF BCM-ECM

4

• B2553: IGNITION RELAY
• B2555: STOP LAMP
• B2556: PUSH-BTN IGN SW
• B2557: VEHICLE SPEED
• B2560: STARTER CONT RELAY
• B2601: SHIFT POSITION
• B2602: SHIFT POSITION
• B2603: SHIFT POSI STATUS
• B2604: PNP SWITCH
• B2605: PNP SWITCH
• B2608: STARTER RELAY
• B260A: IGNITION RELAY
• B260F: ENG STATE SIG LOST
• B2614: ACC RELAY CIRC
• B2615: BLOWER RELAY CIRC
• B2616: IGN RELAY CIRC
• B2617: STARTER RELAY CIRC
• B2618: BCM
• B261A: PUSH-BTN IGN SW
• B26E1: ENG STATE NO RECIV
• C1729: VHCL SPEED SIG ERR
• U0415: VEHICLE SPEED SIG

BCM (BODY CONTROL MODULE)

DEF-43

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

M

A

B

DEF

N

O

P

DTC Index

INFOID:0000000010065038

NOTE:

Details of time display

• CRNT: Displays when there is a malfunction now or after returning to the normal condition until turning igni-

tion switch OFF

→ ON again.

• 1 - 39: Displayed if any previous malfunction is present when current condition is normal. It increases 1

→ 2

→ 3...38 → 39 after returning to the normal condition whenever ignition switch OFF → ON. The counter

remains at 39 even if the number of cycles exceeds it. It is counted from 1 again when turning ignition switch

OFF

→ ON after returning to the normal condition if the malfunction is detected again.

5

• C1704: LOW PRESSURE FL
• C1705: LOW PRESSURE FR
• C1706: LOW PRESSURE RR
• C1707: LOW PRESSURE RL
• C1708: [NO DATA] FL
• C1709: [NO DATA] FR
• C1710: [NO DATA] RR
• C1711: [NO DATA] RL
• C1712: [CHECKSUM ERR] FL
• C1713: [CHECKSUM ERR] FR
• C1714: [CHECKSUM ERR] RR
• C1715: [CHECKSUM ERR] RL
• C1716: [PRESSDATA ERR] FL
• C1717: [PRESSDATA ERR] FR
• C1718: [PRESSDATA ERR] RR
• C1719: [PRESSDATA ERR] RL
• C1720: [CODE ERR] FL
• C1721: [CODE ERR] FR
• C1722: [CODE ERR] RR
• C1723: [CODE ERR] RL
• C1724: [BATT VOLT LOW] FL
• C1725: [BATT VOLT LOW] FR
• C1726: [BATT VOLT LOW] RR
• C1727: [BATT VOLT LOW] RL
• C1734: CONTROL UNIT

6

• B2622: INSIDE ANTENNA
• B2623: INSIDE ANTENNA

Priority

DTC

CONSULT display

Fail-safe

Intelligent Key

warning lamp ON

Tire pressure

monitor warning

lamp ON

Reference page

No DTC is detected.
further testing
may be required.

U1000: CAN COMM CIRCUIT

BCS-32

U1010: CONTROL UNIT (CAN)

BCS-33

U0415: VEHICLE SPEED SIG

BCS-34

B2190: NATS ANTENNA AMP

×

SEC-37

B2191: DIFFERENCE OF KEY

×

SEC-40

B2192: ID DISCORD BCM-ECM

×

SEC-41

B2193: CHAIN OF BCM-ECM

×

SEC-42

B2553: IGNITION RELAY

PCS-46

B2555: STOP LAMP

SEC-43

B2556: PUSH-BTN IGN SW

×

SEC-46

B2557: VEHICLE SPEED

×

×

SEC-48

B2560: STARTER CONT RELAY

×

×

SEC-49

DEF-44

< ECU DIAGNOSIS INFORMATION >

BCM (BODY CONTROL MODULE)

B2562: LOW VOLTAGE

BCS-35

B2601: SHIFT POSITION

×

×

SEC-50

B2602: SHIFT POSITION

×

×

SEC-53

B2603: SHIFT POSI STATUS

×

×

SEC-56

B2604: PNP SWITCH

×

×

SEC-59

B2605: PNP SWITCH

×

×

SEC-61

B2608: STARTER RELAY

×

×

SEC-63

B260A: IGNITION RELAY

×

×

PCS-48

B260F: ENG STATE SIG LOST

×

×

SEC-65

B2614: ACC RELAY CIRC

×

PCS-50

B2615: BLOWER RELAY CIRC

×

PCS-53

B2616: IGN RELAY CIRC

×

PCS-56

B2617: STARTER RELAY CIRC

×

×

SEC-67

B2618: BCM

×

×

PCS-59

B261A: PUSH-BTN IGN SW

×

PCS-60

B2622: INSIDE ANTENNA

DLK-60

B2623: INSIDE ANTENNA

DLK-63

B26E1: ENG STATE NO RES

×

×

SEC-66

C1704: LOW PRESSURE FL

×

WT-43

C1705: LOW PRESSURE FR

×

WT-43

C1706: LOW PRESSURE RR

×

WT-43

C1707: LOW PRESSURE RL

×

WT-43

C1708: [NO DATA] FL

×

WT-13

C1709: [NO DATA] FR

×

WT-13

C1710: [NO DATA] RR

×

WT-13

C1711: [NO DATA] RL

×

WT-13

C1712: [CHECKSUM ERR] FL

×

WT-15

C1713: [CHECKSUM ERR] FR

×

WT-15

C1714: [CHECKSUM ERR] RR

×

WT-15

C1715: [CHECKSUM ERR] RL

×

WT-15

C1716: [PRESSDATA ERR] FL

×

WT-17

C1717: [PRESSDATA ERR] FR

×

WT-17

C1718: [PRESSDATA ERR] RR

×

WT-17

C1719: [PRESSDATA ERR] RL

×

WT-17

C1720: [CODE ERR] FL

×

WT-15

C1721: [CODE ERR] FR

×

WT-15

C1722: [CODE ERR] RR

×

WT-15

C1723: [CODE ERR] RL

×

WT-15

C1724: [BATT VOLT LOW] FL

×

WT-15

C1725: [BATT VOLT LOW] FR

×

WT-15

C1726: [BATT VOLT LOW] RR

×

WT-15

C1727: [BATT VOLT LOW] RL

×

WT-15

CONSULT display

Fail-safe

Intelligent Key

warning lamp ON

Tire pressure

monitor warning

lamp ON

Reference page
