B C S BCM (BODY CONTROL MODULE) BCS-55 < ECU DIAGNOSIS INFORMATION > [BCM] C D E F G H I J K L B A O P N 76 (R/G) Ground Combination switch Output Combination All switch OFF 1.4V Lighting switch high-beam 1.3V Lighting switch 2ND 1.3V Any of the conditions below 1.3V 78 (P) Ground CAN-L Input/ Output — — 79 (L) Ground CAN-H Input/ Output — — 80 (R/L) Ground Key slot illumination Output Key slot illumina- OFF Battery voltage Blinking 6.5V ON 0V 81 (LG) Ground ON indicator lamp Output Ignition switch OFF or ACC 0V ON Battery voltage Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output (+) (-) JPMIA0041GB JPMIA0036GB JPMIA0037GB JPMIA0040GB JPMIA0015GB |
