RF-16

< COMPONENT DIAGNOSIS >

DOOR SWITCH

Is the inspection result normal?

YES

>> GO TO 4

NO

>> GO TO 2

2.

CHECK DOOR SWITCH CIRCUIT

1. Disconnect BCM connector.

Terminals

Door condition

Voltage (V)

(Approx.)

(+)

(–)

BCM

connector

Terminal

A: M18

58

Ground

Driver side

OPEN

0

CLOSE

32

Passenger side

OPEN

0

CLOSE

B: M21

148

Rear RH

OPEN

0

CLOSE

149

Rear LH

OPEN

0

CLOSE

JPMIA0011GB

JPMIA0011GB

JPMIA0011GB

JPMIA0011GB

DOOR SWITCH

RF-17

< COMPONENT DIAGNOSIS >

C

D

E

F

G

H

I

J

L

M

A

B

RF

N

O

P

2. Check continuity between BCM connector and door switch con-

nector.

3. Check continuity between BCM connector and ground.

Is the inspection result normal?

YES

>> GO TO 3

NO

>> Repair or replace harness between BCM and door switch.

3.

CHECK DOOR SWITCH

Refer to

RF-17, "Component Inspection"

.

Is the inspection result normal?

YES

>> GO TO 4

NO

>> Replace malfunctioning door switch.

4.

CHECK INTERMITTENT INCIDENT

Refer to

GI-42, "Intermittent Incident"

.

>> Inspection End.

Component Inspection

INFOID:0000000004496857

1.

CHECK DOOR SWITCH

1. Turn ignition switch OFF.

2. Disconnect door switch connector.

3. Check door switch.

Is the inspection result normal?

YES

>> Inspection End.

NO

>> Replace malfunction door switch.

BCM connector

Terminal

Door switch

connector

Terminal

Continuity

A: M18

58

C: B8 (Driver side)

2

Yes

32

C: B108 (Passenger side)

B: M21

148

C: B116 (Rear RH)

149

C: B18 (Rear LH)

BCM connector

Terminal

Ground

Continuity

A: M18

58

No

32

B: M21

148

149

ALKIA0332ZZ

Terminal

Door switch condition

Continuity

Door switch

2

Ground part of

door switch

Pressed

No

Released

Yes

WIIA0644E

RF-18

< ECU DIAGNOSIS >

BCM (BODY CONTROL MODULE)

ECU DIAGNOSIS

BCM (BODY CONTROL MODULE)

Reference Value

INFOID:0000000004496858

VALUES ON THE DIAGNOSIS TOOL

Monitor Item

Condition

Value/Status

FR WIPER HI

Other than front wiper switch HI

OFF

Front wiper switch HI

ON

FR WIPER LOW

Other than front wiper switch LO

OFF

Front wiper switch LO

ON

FR WASHER SW

Front washer switch OFF

OFF

Front washer switch ON

ON

FR WIPER INT

Other than front wiper switch INT

OFF

Front wiper switch INT

ON

FR WIPER STOP

Front wiper is not in STOP position

OFF

Front wiper is in STOP position

ON

INT VOLUME

Wiper intermittent dial is in a dial position 1 - 7

Wiper intermittent dial position

TURN SIGNAL R

Other than turn signal switch RH

OFF

Turn signal switch RH

ON

TURN SIGNAL L

Other than turn signal switch LH

OFF

Turn signal switch LH

ON

TAIL LAMP SW

Other than lighting switch 1ST and 2ND

OFF

Lighting switch 1ST or 2ND

ON

HI BEAM SW

Other than lighting switch HI

OFF

Lighting switch HI

ON

HEAD LAMP SW 1

Other than lighting switch 2ND

OFF

Lighting switch 2ND

ON

HEAD LAMP SW 2

Other than lighting switch 2ND

OFF

Lighting switch 2ND

ON

PASSING SW

Other than lighting switch PASS

OFF

Lighting switch PASS

ON

AUTO LIGHT SW

Other than lighting switch AUTO

OFF

Lighting switch AUTO

ON

FR FOG SW

Front fog lamp switch OFF

OFF

Front fog lamp switch ON

ON

DOOR SW-DR

Front door LH closed

OFF

Front door LH opened

ON

DOOR SW-AS

Front door RH closed

OFF

Front door RH opened

ON

DOOR SW-RR

Rear door RH closed

OFF

Rear door RH opened

ON

DOOR SW-RL

Rear door LH closed

OFF

Rear door LH opened

ON

BCM (BODY CONTROL MODULE)

RF-19

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

J

L

M

A

B

RF

N

O

P

DOOR SW-BK

NOTE:
This item is displayed, but cannot be monitored.

OFF

CDL LOCK SW

Other than power door lock switch LOCK

OFF

Door lock/unlock switch LOCK

ON

CDL UNLOCK SW

Other than door lock/unlock switch UNLOCK

OFF

Door lock/unlock switch UNLOCK

ON

KEY CYL LK-SW

Other than front door LH key cylinder LOCK position

OFF

Front door LH key cylinder LOCK position

ON

KEY CYL UN-SW

Other than front door LH key cylinder UNLOCK position

OFF

Front door LH key cylinder UNLOCK position

ON

KEY CYL SW-TR

NOTE:
This item is displayed, but cannot be monitored.

OFF

HAZARD SW

When hazard switch is not pressed

OFF

When hazard switch is pressed

ON

REAR DEF SW

When rear window defogger switch is pressed

ON

FAN ON SIG

When AUTO switch or fan switch is pressed

ON

AIR COND SW

When A/C switch is pressed

ON

TR CANCEL SW

Trunk lid opener cancel switch OFF

OFF

Trunk lid opener cancel switch ON

ON

TR/BD OPEN SW

Trunk lid opener switch OFF

OFF

While the trunk lid opener switch is turned ON

ON

TRNK/HAT MNTR

Trunk lid closed

OFF

Trunk lid opened

ON

RKE-LOCK

When LOCK button of Intelligent Key is not pressed

OFF

When LOCK button of Intelligent Key is pressed

ON

RKE-UNLOCK

When UNLOCK button of Intelligent Key is not pressed

OFF

When UNLOCK button of Intelligent Key is pressed

ON

RKE-TR/BD

When TRUNK OPEN button of Intelligent Key is not pressed

OFF

When TRUNK OPEN button of Intelligent Key is pressed

ON

RKE-PANIC

When PANIC button of Intelligent Key is not pressed

OFF

When PANIC button of Intelligent Key is pressed

ON

RKE-P/W OPEN

When UNLOCK button of Intelligent Key is not pressed and held

OFF

When UNLOCK button of Intelligent Key is pressed and held

ON

RKE-MODE CHG

When LOCK/UNLOCK button of Intelligent Key is not pressed and
held simultaneously

OFF

When LOCK/UNLOCK button of Intelligent Key is pressed and held
simultaneously

ON

OPTICAL SENSOR

When outside of the vehicle is bright

Close to 5 V

When outside of the vehicle is dark

Close to 0 V

REQ SW-DR

When front door LH request switch is not pressed

OFF

When front door LH request switch is pressed

ON

REQ SW-AS

When front door RH request switch is not pressed

OFF

When front door RH request switch is pressed

ON

REQ SW-BD/TR

When trunk request switch is not pressed

OFF

When trunk request switch is pressed

ON

Monitor Item

Condition

Value/Status
