ILLUMINATION

INL-47

< COMPONENT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

M

A

B

INL

N

O

P

ABLIA0881GB

INL-48

< ECU DIAGNOSIS >

BCM (BODY CONTROL MODULE)

ECU DIAGNOSIS

BCM (BODY CONTROL MODULE)

Reference Value

INFOID:0000000004469739

VALUES ON THE DIAGNOSIS TOOL

Monitor Item

Condition

Value/Status

FR WIPER HI

Other than front wiper switch HI

OFF

Front wiper switch HI

ON

FR WIPER LOW

Other than front wiper switch LO

OFF

Front wiper switch LO

ON

FR WASHER SW

Front washer switch OFF

OFF

Front washer switch ON

ON

FR WIPER INT

Other than front wiper switch INT

OFF

Front wiper switch INT

ON

FR WIPER STOP

Front wiper is not in STOP position

OFF

Front wiper is in STOP position

ON

INT VOLUME

Wiper intermittent dial is in a dial position 1 - 7

Wiper intermittent dial position

TURN SIGNAL R

Other than turn signal switch RH

OFF

Turn signal switch RH

ON

TURN SIGNAL L

Other than turn signal switch LH

OFF

Turn signal switch LH

ON

TAIL LAMP SW

Other than lighting switch 1ST and 2ND

OFF

Lighting switch 1ST or 2ND

ON

HI BEAM SW

Other than lighting switch HI

OFF

Lighting switch HI

ON

HEAD LAMP SW 1

Other than lighting switch 2ND

OFF

Lighting switch 2ND

ON

HEAD LAMP SW 2

Other than lighting switch 2ND

OFF

Lighting switch 2ND

ON

PASSING SW

Other than lighting switch PASS

OFF

Lighting switch PASS

ON

AUTO LIGHT SW

Other than lighting switch AUTO

OFF

Lighting switch AUTO

ON

FR FOG SW

Front fog lamp switch OFF

OFF

Front fog lamp switch ON

ON

DOOR SW-DR

Front door LH closed

OFF

Front door LH opened

ON

DOOR SW-AS

Front door RH closed

OFF

Front door RH opened

ON

DOOR SW-RR

Rear door RH closed

OFF

Rear door RH opened

ON

DOOR SW-RL

Rear door LH closed

OFF

Rear door LH opened

ON

BCM (BODY CONTROL MODULE)

INL-49

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

J

K

M

A

B

INL

N

O

P

DOOR SW-BK

NOTE:
This item is displayed, but cannot be monitored.

OFF

CDL LOCK SW

Other than power door lock switch LOCK

OFF

Door lock/unlock switch LOCK

ON

CDL UNLOCK SW

Other than door lock/unlock switch UNLOCK

OFF

Door lock/unlock switch UNLOCK

ON

KEY CYL LK-SW

Other than front door LH key cylinder LOCK position

OFF

Front door LH key cylinder LOCK position

ON

KEY CYL UN-SW

Other than front door LH key cylinder UNLOCK position

OFF

Front door LH key cylinder UNLOCK position

ON

KEY CYL SW-TR

NOTE:
This item is displayed, but cannot be monitored.

OFF

HAZARD SW

When hazard switch is not pressed

OFF

When hazard switch is pressed

ON

REAR DEF SW

When rear window defogger switch is pressed

ON

FAN ON SIG

When AUTO switch or fan switch is pressed

ON

AIR COND SW

When A/C switch is pressed

ON

TR CANCEL SW

Trunk lid opener cancel switch OFF

OFF

Trunk lid opener cancel switch ON

ON

TR/BD OPEN SW

Trunk lid opener switch OFF

OFF

While the trunk lid opener switch is turned ON

ON

TRNK/HAT MNTR

Trunk lid closed

OFF

Trunk lid opened

ON

RKE-LOCK

When LOCK button of Intelligent Key is not pressed

OFF

When LOCK button of Intelligent Key is pressed

ON

RKE-UNLOCK

When UNLOCK button of Intelligent Key is not pressed

OFF

When UNLOCK button of Intelligent Key is pressed

ON

RKE-TR/BD

When TRUNK OPEN button of Intelligent Key is not pressed

OFF

When TRUNK OPEN button of Intelligent Key is pressed

ON

RKE-PANIC

When PANIC button of Intelligent Key is not pressed

OFF

When PANIC button of Intelligent Key is pressed

ON

RKE-P/W OPEN

When UNLOCK button of Intelligent Key is not pressed and held

OFF

When UNLOCK button of Intelligent Key is pressed and held

ON

RKE-MODE CHG

When LOCK/UNLOCK button of Intelligent Key is not pressed and
held simultaneously

OFF

When LOCK/UNLOCK button of Intelligent Key is pressed and held
simultaneously

ON

OPTICAL SENSOR

When outside of the vehicle is bright

Close to 5 V

When outside of the vehicle is dark

Close to 0 V

REQ SW-DR

When front door LH request switch is not pressed

OFF

When front door LH request switch is pressed

ON

REQ SW-AS

When front door RH request switch is not pressed

OFF

When front door RH request switch is pressed

ON

REQ SW-BD/TR

When trunk request switch is not pressed

OFF

When trunk request switch is pressed

ON

Monitor Item

Condition

Value/Status

INL-50

< ECU DIAGNOSIS >

BCM (BODY CONTROL MODULE)

PUSH SW

When push-button ignition switch is not pressed

OFF

When push-button ignition switch is pressed

ON

IGN RLY -F/B

Ignition switch OFF or ACC

OFF

Ignition switch ON

ON

ACC RLY -F/B

Ignition switch OFF

OFF

Ignition switch ACC or ON

ON

BRAKE SW 1

When the brake pedal is not depressed

ON

When the brake pedal is depressed

OFF

DETE/CANCL SW

When selector lever is in P position

OFF

When selector lever is in any position other than P

ON

SFT PN/N SW

When selector lever is in any position other than P or N

OFF

When selector lever is in P or N position

ON

S/L -LOCK

Electronic steering column lock LOCK status

OFF

Electronic steering column lock UNLOCK status

ON

S/L -UNLOCK

Electronic steering column lock UNLOCK status

OFF

Electronic steering column lock LOCK status

ON

S/L RELAY-F/B

Ignition switch OFF or ACC

OFF

Ignition switch ON

ON

UNLK SEN-DR

Front door LH UNLOCK status

OFF

Front door LH LOCK status

ON

PUSH SW -IPDM

When push-button ignition switch is not pressed (IPDM E/R sends
via CAN)

OFF

When push-button ignition switch is pressed (IPDM E/R sends via
CAN)

ON

IGN RLY1 F/B

Ignition switch OFF or ACC

OFF

Ignition switch ON

ON

DETE SW -IPDM

When selector lever is in P position (IPDM E/R sends via CAN)

OFF

When selector lever is in any position other than P (IPDM E/R sends
via CAN)

ON

SFT PN -IPDM

When selector lever is in any position other than P or N (IPDM E/R
sends via CAN)

OFF

When selector lever is in P or N position (IPDM E/R sends via CAN) ON

SFT P -MET

When selector lever is in any position other than P (combination
meter sends via CAN)

OFF

When selector lever is in P position (combination meter sends via
CAN)

ON

SFT N -MET

When selector lever is in any position other than N  (combination
meter sends via CAN)

OFF

When selector lever is in N position  (combination meter sends via
CAN)

ON

ENGINE STATE

Engine stopped

STOP

While the engine stalls

STALL

At engine cranking

CRANK

Engine running

RUN

S/L LOCK-IPDM

Electronic steering column lock LOCK status (IPDM E/R sends via
CAN)

OFF

Electronic steering column lock UNLOCK status (IPDM E/R sends
via CAN)

ON

Monitor Item

Condition

Value/Status
