Nissan Altima HL32 Hybrid. Manual - part 1136





BCM (BODY CONTROL MODULE)

WW-43

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

J

K

M

A

B

WW

N

O

P

66

(R)

Ground

Instrument panel an-
tenna (-)

Output

Ignition switch
OFF

When Intelligent Key is in
the passenger compart-
ment

When Intelligent Key is not
in the passenger compart-
ment

67

(G)

Ground

Instrument panel an-
tenna (+)

Output

Ignition switch
OFF

When Intelligent Key is in
the passenger compart-
ment

When Intelligent Key is not
in the passenger compart-
ment

68

(G/O)

Ground

NATS antenna amp
(built in key slot)

Input/

Output

During waiting

Ignition switch is pressed
while inserting the Intelli-
gent Key into the key slot.

Just after pressing ignition
switch. Pointer of tester should
move.

69

(O)

Ground

NATS antenna amp
(built in key slot)

Input/

Output

During waiting

Ignition switch is pressed
while inserting the Intelli-
gent Key into the key slot.

Just after pressing ignition
switch. Pointer of tester should
move.

70

(R/B)

Ground

Ignition relay-2 con-
trol

Output Ignition switch

OFF or ACC

0V

ON

Battery voltage

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

(+)

(-)

JMKIA0062GB

JMKIA0063GB

JMKIA0062GB

JMKIA0063GB

WW-44

< ECU DIAGNOSIS >

BCM (BODY CONTROL MODULE)

71

(L/O)

Ground

Remote keyless entry
receiver signal

Input/

Output

During waiting

When operating either button on Intelligent Key

75

(R/Y)

Ground

Combination switch
INPUT 5

Input

Combination
switch

All switch OFF
(Wiper intermittent dial 4)

1.4V

Front fog lamp switch ON
(Wiper intermittent dial 4)

1.3V

Any of the conditions below
with all switch OFF
• Wiper intermittent dial 1
• Wiper intermittent dial 2
• Wiper intermittent dial 6
• Wiper intermittent dial 7

1.3V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

(+)

(-)

JMKIA0064GB

JMKIA0065GB

JPMIA0041GB

JPMIA0037GB

JPMIA0040GB

BCM (BODY CONTROL MODULE)

WW-45

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

J

K

M

A

B

WW

N

O

P

76

(R/G)

Ground

Combination switch
INPUT 3

Input

Combination
switch

All switch OFF
(Wiper intermittent dial 4)

1.4V

Lighting switch high-beam
(Wiper intermittent dial 4)

1.3V

Lighting switch 2ND
(Wiper intermittent dial 4)

1.3V

Any of the conditions below
with all switch OFF
• Wiper intermittent dial 1
• Wiper intermittent dial 2
• Wiper intermittent dial 3

1.3V

77

(BR)

Ground

Push-button ignition
switch

Input

Engine switch
(push switch)

Pressed

0V

Not pressed

Battery voltage

78

(P)

Ground CAN-L

Input/

Output

79

(L)

Ground CAN-H

Input/

Output

80

(R/L)

Ground Key slot illumination

Output

Key slot illumina-
tion

OFF

0V

Blinking

6.5V

ON

Battery voltage

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

(+)

(-)

JPMIA0041GB

JPMIA0036GB

JPMIA0037GB

JPMIA0040GB

JPMIA0015GB

WW-46

< ECU DIAGNOSIS >

BCM (BODY CONTROL MODULE)

81

(LG)

Ground ON indicator lamp

Output Ignition switch

OFF or ACC

Battery voltage

ON

0V

83

(L)

Ground ACC relay control

Output Ignition switch

OFF

0V

ACC or ON

Battery voltage

84

(Y/R)

Ground

ECTV device (detent
switch)

Output

Battery voltage

85

(L/O)

Ground

Electronic steering
column lock condition
No. 1

Input

Electronic steer-
ing column lock

Lock status

0V

Unlock status

Battery voltage

86

(G/R)

Ground

Electronic steering
column lock condition
No. 2

Input

Electronic steer-
ing column lock

Lock status

Battery voltage

Unlock status

0V

87

(G/B)

Ground

ECTV device (detent
switch)

Input

Selector lever

P position

0V

Any position other than P

Battery voltage

88

(P/L)

Ground

Front door RH re-
quest switch

Input

Front door RH re-
quest switch

ON (pressed)

0V

OFF (not pressed)

1.0V

89

(B/W)

Ground

Front door LH re-
quest switch

Input

Front door LH re-
quest switch

ON (pressed)

0V

OFF (not pressed)

1.0V

90

(Y)

Ground

Front blower motor
relay control

Output Ignition switch

OFF or ACC

0V

ON

Battery voltage

91

(L/R)

Ground

Remote keyless entry
receiver power sup-
ply

Output Ignition switch OFF

Battery voltage

94

(G/Y)

Ground

Electronic steering
column lock CPU
power supply

Output Ignition switch

OFF or ACC

Battery voltage

ON

0V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

(+)

(-)

JPMIA0016GB

JPMIA0016GB
