WCS-62 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) 71 (L/O) Ground Remote keyless entry Input/ Output During waiting When operating either button on Intelligent Key 75 (R/Y) Ground Combination switch Input Combination All switch OFF 1.4V Front fog lamp switch ON 1.3V Any of the conditions below 1.3V Terminal No. (Wire color) Description Condition Value (Approx.) Signal name Input/ Output (+) (-) JMKIA0064GB JMKIA0065GB JPMIA0041GB JPMIA0037GB JPMIA0040GB |
