AV-96

< COMPONENT DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

MICROPHONE SIGNAL CIRCUIT

Check signal between Bluetooth control unit harness connector

B126 terminals 7 and 8.

Are voltage readings as specified?

YES

>> Replace Bluetooth control unit. Refer to

AV-145, "Removal and Installation"

.

NO

>> Replace microphone. Refer to

AV-143, "Removal and Installation"

.

7 - 8:

When giving a voice

AWNIA0907ZZ

PKIB5037J

AV

AUDIO UNIT

AV-97

< ECU DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

ECU DIAGNOSIS

AUDIO UNIT

Reference Value

INFOID:0000000004219463

TERMINAL LAYOUT

PHYSICAL VALUES - WITH BLUETOOTH

AWNIA0046ZZ

Terminal

 (Wire color)

Item

Signal in-

put/out-

put

Condition

Reference value

+

–

Ignition

switch

Operation

1

(B/P)

Ground

Amp. ON sig-
nal

Output

ON

–

More than approx. 6.5V

2

(G)

3

(R)

Audio sound
signal front LH

Output

ON

Receive audio sig-
nal

4

(GR/V)

5

(W/L)

Audio sound
signal rear LH

Output

ON

Receive audio sig-
nal

6

(W/G)

Ground

Remote con-
trol A

Input

ON

Press SEEK
DOWN switch.

0.7V

Press SEEK UP
switch.

1.3V

Press

switch.

2.0V

Except for above.

3.3V

7

 (V/Y)

Ground

ACC signal

Input

ON

Ignition switch
ACC or ON

Battery voltage

SKIA0177E

SKIA0177E

AV-98

< ECU DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

AUDIO UNIT

11

(B)

12

(W)

Audio sound
signal front
RH

Output

ON

Receive audio sig-
nal

13

(V)

14

(LG)

Audio sound
signal rear RH

Output

ON

Receive audio sig-
nal

15

(L/B)

–

Remote con-
trol ground

Input

–

–

–

16

(GR/L)

Ground

Remote con-
trol B

Input

ON

Press SOURCE
switch.

 0V

Press

switch.

0.7V

Press VOL UP
switch.

1.3V

Press VOL DOWN
switch

2V

Except for above.

3.3V

18

(V/W)

Ground

Vehicle speed
signal (8-
pulse)

Input

ON

When vehicle
speed is approx.
40 km/h (25 MPH)

19

(Y/R)

Ground

Battery power

Input

–

–

Battery voltage

21

–

M-CAN +

–

–

–

–

22

–

M-CAN -

–

–

–

–

23

–

Shield

–

–

–

Approx. 0V

25

–

Tel. Shield

–

–

–

Approx. 0V

26

(BR)

27

(Y)

Telephone au-
dio in

–

–

–

–

28

(R/W)

Ground

Telephone ON
signal

Input

ON

–

–

Terminal

 (Wire color)

Item

Signal in-

put/out-

put

Condition

Reference value

+

–

Ignition

switch

Operation

SKIA0177E

SKIA0177E

PKIA1935E

AV

AUDIO UNIT

AV-99

< ECU DIAGNOSIS >

[BOSE AUDIO WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

PHYSICAL VALUES - WITHOUT BLUETOOTH

32

(Y/L)

31

 (W/L)

Audio left
channel
sound signal
from satellite
radio tuner

Input

ON

Receive audio sig-
nal

34

(BR/L)

33

 (Y/G)

Audio right
channel
sound signal
from satellite
radio tuner

Input

ON

Receive audio sig-
nal

38

(R)

Ground

Satellite radio
tuner request
to audio unit

Input

ON

Turn audio unit ON

5V

39

(G)

Ground

Audio RX

Input

Operate audio vol-

ume

40

 (B)

Ground

Audio TX

Output

Operate audio vol-

ume

75

(B)

Ground

Amp power
supply

Output

ON

Turn audio unit ON

Battery voltage

76

(B)

Ground

Main antenna

Input

ON

Turn audio unit ON

–

Terminal

 (Wire color)

Item

Signal in-

put/out-

put

Condition

Reference value

+

–

Ignition

switch

Operation

SKIA0177E

SKIA0177E

SKIA4403E
