BRC-212

< ECU DIAGNOSIS INFORMATION >

[TYPE 2]

ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)

C1115

ABS SENSOR [ABNORMAL SIGNAL]

BRC-168, "Description"

C1116

STOP LAMP SW

BRC-171, "Description"

C1120

FR LH IN ABS SOL

BRC-173, "Description"

C1121

FR LH OUT ABS SOL

BRC-176, "Description"

C1122

FR RH IN ABS SOL

BRC-173, "Description"

C1123

FR RH OUT ABS SOL

BRC-176, "Description"

C1124

RR LH IN ABS SOL

BRC-173, "Description"

C1125

RR LH OUT ABS SOL

BRC-176, "Description"

C1126

RR RH IN ABS SOL

BRC-173, "Description"

C1127

RR RH OUT ABS SOL

BRC-176, "Description"

C1130

ENGINE SIGNAL 1

BRC-179, "Description"

C1131

ENGINE SIGNAL 2

C1132

ENGINE SIGNAL 3

C1133

ENGINE SIGNAL 4

C1136

ENGINE SIGNAL 6

C1140

ACTUATOR RLY

BRC-180, "Description"

C1143

ST ANG SEN CIRCUIT

BRC-182, "Description"

C1144

ST ANG SEN SIGNAL

C1145

YAW RATE SENSOR

BRC-166, "Description"

C1146

SIDE G-SEN CIRCUIT

C1155

BR FLUID LEVEL LOW

BRC-185, "Description"

C1156

ST ANG SEN COM CIR

BRC-188, "Description"

C1160

DECEL G SEN SET

BRC-189, "Description"

C1163

ST ANGL SEN SAFE

BRC-190, "Description"

C1164

CV1

BRC-191, "Description"

C1165

CV2

C1166

SV1

C1167

SV2

C1170

VARIANT CODING

BRC-163, "DTC Logic"

C1187

ABS DIFLOCK CONTROLLER NG

BRC-194, "Description"

U1000

CAN COMM CIRCUIT

BRC-195, "Description"

DTC

Items (CONSULT screen terms)

Reference

BRAKE CONTROL SYSTEM - VDC

BRC-213

< WIRING DIAGRAM >

[TYPE 2]

C

D

E

G

H

I

J

K

L

M

A

B

BRC

N

O

P

WIRING DIAGRAM

BRAKE CONTROL SYSTEM - VDC

Wiring Diagram - VDC WITH HILL DESCENT CONTROL/HILL START ASSIST

INFOID:0000000009479539

ABFWA0370GB

BRC-214

< WIRING DIAGRAM >

[TYPE 2]

BRAKE CONTROL SYSTEM - VDC

ABFWA0371GB

BRAKE CONTROL SYSTEM - VDC

BRC-215

< WIRING DIAGRAM >

[TYPE 2]

C

D

E

G

H

I

J

K

L

M

A

B

BRC

N

O

P

ABFIA0748GB
