Nissan Sentra. Manual - part 658

MWI-78

< REMOVAL AND INSTALLATION >

COMBINATION METER

1. Release the pawls and remove the front cover.

: Pawl

ASSEMBLY

Assembly is in the reverse order of disassembly.

CAUTION:

• Do not touch the display, pointer, the inside of front cover and the printed area of the dial during the

work.

• Keep away from magnetic sources.

ALNIA1466ZZ

MWI

STEERING SWITCH

MWI-79

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

STEERING SWITCH

Removal and Installation

INFOID:0000000009758318

For removal and installation of the steering switch, refer to

AV-62, "Removal and Installation"

.

MWI-80

< REMOVAL AND INSTALLATION >

ILLUMINATION CONTROL SWITCH

ILLUMINATION CONTROL SWITCH

Removal and Installation

INFOID:0000000009758319

For removal and installation of the illumination control switch refer to

INL-57, "Removal and Installation"

.
