AV-204

< REMOVAL AND INSTALLATION >

[DISPLAY AUDIO WITH BOSE]

FRONT TWEETER

FRONT TWEETER

Removal and Installation

INFOID:0000000009758913

REMOVAL

1. Remove the front pillar finisher. Refer to

INT-24, "FRONT PILLAR FINISHER : Removal and Installation"

.

2. Disconnect the harness connector (B) from the front tweeter

speaker.

3. Remove the front tweeter speaker screw (A) from the front

tweeter speaker (1) and remove.

INSTALLATION

Installation is in the reverse order of removal.

ALNIA1405ZZ

AV

FRONT DOOR SPEAKER

AV-205

< REMOVAL AND INSTALLATION >

[DISPLAY AUDIO WITH BOSE]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

FRONT DOOR SPEAKER

Removal and Installation

INFOID:0000000009758914

REMOVAL

1. Remove the front door finisher. Refer to

INT-15, "Removal and Installation"

.

2. Remove the front door speaker screws (B).
3. Disconnect the harness connector (A) from the front door

speaker (1) and remove.

INSTALLATION

Installation is in the reverse order of removal.

ALNIA1406ZZ

AV-206

< REMOVAL AND INSTALLATION >

[DISPLAY AUDIO WITH BOSE]

REAR DOOR SPEAKER

REAR DOOR SPEAKER

Removal and Installation

INFOID:0000000009758915

REMOVAL

1. Remove the rear door finisher. Refer to

INT-19, "Removal and Installation"

.

2. Remove the rear door speaker screws (A).
3. Disconnect the harness connector (B) from the rear door

speaker (1) and remove.

INSTALLATION

Installation is in the reverse order of removal.

ALNIA1416ZZ

AV

REAR WOOFER

AV-207

< REMOVAL AND INSTALLATION >

[DISPLAY AUDIO WITH BOSE]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

REAR WOOFER

Removal and Installation

INFOID:0000000009758916

REMOVAL

1. Remove the rear parcel shelf finisher. Refer to

INT-33, "Removal and Installation"

.

2. Remove the rear woofer screws (A).
3. Disconnect the harness connector from the rear woofer (1) and

remove.

INSTALLATION

Installation is in the reverse order of removal.

ALNIA1407ZZ
