EV BATTERY SYSTEM

EVB-47

< ECU DIAGNOSIS INFORMATION >

D

E

F

G

H

I

J

K

L

M

A

B

EVB

N

O

P

P318D

COMMUNICATION ERROR

×

1

EVB-99

P318E

COMMUNICATION ERROR

×

1

EVB-100

P3191

COMMUNICATION ERROR

—

1

EVB-101

P3196

COMMUNICATION ERROR

—

1

EVB-102

P3198

COMMUNICATION ERROR

—

1

EVB-103

P3199

COMMUNICATION ERROR

×

1

EVB-104

P319C

COMMUNICATION ERROR

—

1

EVB-105

P31A4

CAN ERROR VCM

×

1

EVB-106

P31A7

CAN ERROR INV/MC

—

1

EVB-107

P3302

CELL OVER VOLTAGE MODULE1

×

1

EVB-108

P3303

CELL OVER VOLTAGE MODULE2

×

1

EVB-108

P3304

CELL OVER VOLTAGE MODULE3

×

1

EVB-108

P3305

CELL OVER VOLTAGE MODULE4

×

1

EVB-108

P3306

CELL OVER VOLTAGE MODULE5

×

1

EVB-108

P3307

CELL OVER VOLTAGE MODULE6

×

1

EVB-108

P3308

CELL OVER VOLTAGE MODULE7

×

1

EVB-108

P3309

CELL OVER VOLTAGE MODULE8

×

1

EVB-108

P330A

CELL OVER VOLTAGE MODULE9

×

1

EVB-108

P330B

CELL OVER VOLTAGE MODULE10

×

1

EVB-108

P330C

CELL OVER VOLTAGE MODULE11

×

1

EVB-108

P330D

CELL OVER VOLTAGE MODULE12

×

1

EVB-108

P330E

CELL OVER VOLTAGE MODULE13

×

1

EVB-112

P330F

CELL OVER VOLTAGE MODULE14

×

1

EVB-112

P3310

CELL OVER VOLTAGE MODULE15

×

1

EVB-112

P3311

CELL OVER VOLTAGE MODULE16

×

1

EVB-112

P3312

CELL OVER VOLTAGE MODULE17

×

1

EVB-112

P3313

CELL OVER VOLTAGE MODULE18

×

1

EVB-112

P3314

CELL OVER VOLTAGE MODULE19

×

1

EVB-112

P3315

CELL OVER VOLTAGE MODULE20

×

1

EVB-112

P3316

CELL OVER VOLTAGE MODULE21

×

1

EVB-112

P3317

CELL OVER VOLTAGE MODULE22

×

1

EVB-112

P3318

CELL OVER VOLTAGE MODULE23

×

1

EVB-112

P3319

CELL OVER VOLTAGE MODULE24

×

1

EVB-112

P331A

CELL OVER VOLTAGE MODULE25

×

1

EVB-116

P331B

CELL OVER VOLTAGE MODULE26

×

1

EVB-116

P331C

CELL OVER VOLTAGE MODULE27

×

1

EVB-116

P331D

CELL OVER VOLTAGE MODULE28

×

1

EVB-116

P331E

CELL OVER VOLTAGE MODULE29

×

1

EVB-116

P331F

CELL OVER VOLTAGE MODULE30

×

1

EVB-116

P3320

CELL OVER VOLTAGE MODULE31

×

1

EVB-116

P3321

CELL OVER VOLTAGE MODULE32

×

1

EVB-116

P3322

CELL OVER VOLTAGE MODULE33

×

1

EVB-116

P3323

CELL OVER VOLTAGE MODULE34

×

1

EVB-116

DTC

CONSULT screen items

EV system

warning

lamp

Trip

Reference

EVB-48

< ECU DIAGNOSIS INFORMATION >

EV BATTERY SYSTEM

P3324

CELL OVER VOLTAGE MODULE35

×

1

EVB-116

P3325

CELL OVER VOLTAGE MODULE36

×

1

EVB-116

P3326

CELL OVER VOLTAGE MODULE37

×

1

EVB-119

P3327

CELL OVER VOLTAGE MODULE38

×

1

EVB-119

P3328

CELL OVER VOLTAGE MODULE39

×

1

EVB-119

P3329

CELL OVER VOLTAGE MODULE40

×

1

EVB-119

P332A

CELL OVER VOLTAGE MODULE41

×

1

EVB-119

P332B

CELL OVER VOLTAGE MODULE42

×

1

EVB-119

P332C

CELL OVER VOLTAGE MODULE43

×

1

EVB-119

P332D

CELL OVER VOLTAGE MODULE44

×

1

EVB-119

P332E

CELL OVER VOLTAGE MODULE45

×

1

EVB-119

P332F

CELL OVER VOLTAGE MODULE46

×

1

EVB-119

P3330

CELL OVER VOLTAGE MODULE47

×

1

EVB-119

P3331

CELL OVER VOLTAGE MODULE48

×

1

EVB-119

P3375

CELL OVER DISCHARGE MODULE1

×

1

EVB-122

P3376

CELL OVER DISCHARGE MODULE2

×

1

EVB-122

P3377

CELL OVER DISCHARGE MODULE3

×

1

EVB-122

P3378

CELL OVER DISCHARGE MODULE4

×

1

EVB-122

P3379

CELL OVER DISCHARGE MODULE5

×

1

EVB-122

P337A

CELL OVER DISCHARGE MODULE6

×

1

EVB-122

P337B

CELL OVER DISCHARGE MODULE7

×

1

EVB-122

P337C

CELL OVER DISCHARGE MODULE8

×

1

EVB-122

P337D

CELL OVER DISCHARGE MODULE9

×

1

EVB-122

P337E

CELL OVER DISCHARGE MODULE10

×

1

EVB-122

P337F

CELL OVER DISCHARGE MODULE11

×

1

EVB-122

P3380

CELL OVER DISCHARGE MODULE12

×

1

EVB-122

P3381

CELL OVER DISCHARGE MODULE13

×

1

EVB-126

P3382

CELL OVER DISCHARGE MODULE14

×

1

EVB-126

P3383

CELL OVER DISCHARGE MODULE15

×

1

EVB-126

P3384

CELL OVER DISCHARGE MODULE16

×

1

EVB-126

P3385

CELL OVER DISCHARGE MODULE17

×

1

EVB-126

P3386

CELL OVER DISCHARGE MODULE18

×

1

EVB-126

P3387

CELL OVER DISCHARGE MODULE19

×

1

EVB-126

P3388

CELL OVER DISCHARGE MODULE20

×

1

EVB-126

P3389

CELL OVER DISCHARGE MODULE21

×

1

EVB-126

P338A

CELL OVER DISCHARGE MODULE22

×

1

EVB-126

P338B

CELL OVER DISCHARGE MODULE23

×

1

EVB-126

P338C

CELL OVER DISCHARGE MODULE24

×

1

EVB-126

P338D

CELL OVER DISCHARGE MODULE25

×

1

EVB-130

P338E

CELL OVER DISCHARGE MODULE26

×

1

EVB-130

P338F

CELL OVER DISCHARGE MODULE27

×

1

EVB-130

P3390

CELL OVER DISCHARGE MODULE28

×

1

EVB-130

P3391

CELL OVER DISCHARGE MODULE29

×

1

EVB-130

DTC

CONSULT screen items

EV system

warning

lamp

Trip

Reference

EV BATTERY SYSTEM

EVB-49

< ECU DIAGNOSIS INFORMATION >

D

E

F

G

H

I

J

K

L

M

A

B

EVB

N

O

P

P3392

CELL OVER DISCHARGE MODULE30

×

1

EVB-130

P3393

CELL OVER DISCHARGE MODULE31

×

1

EVB-130

P3394

CELL OVER DISCHARGE MODULE32

×

1

EVB-130

P3395

CELL OVER DISCHARGE MODULE33

×

1

EVB-130

P3396

CELL OVER DISCHARGE MODULE34

×

1

EVB-130

P3397

CELL OVER DISCHARGE MODULE35

×

1

EVB-130

P3398

CELL OVER DISCHARGE MODULE36

×

1

EVB-130

P3399

CELL OVER DISCHARGE MODULE37

×

1

EVB-133

P339A

CELL OVER DISCHARGE MODULE38

×

1

EVB-133

P339B

CELL OVER DISCHARGE MODULE39

×

1

EVB-133

P339C

CELL OVER DISCHARGE MODULE40

×

1

EVB-133

P339D

CELL OVER DISCHARGE MODULE41

×

1

EVB-133

P339E

CELL OVER DISCHARGE MODULE42

×

1

EVB-133

P339F

CELL OVER DISCHARGE MODULE43

×

1

EVB-133

P33A0

CELL OVER DISCHARGE MODULE44

×

1

EVB-133

P33A1

CELL OVER DISCHARGE MODULE45

×

1

EVB-133

P33A2

CELL OVER DISCHARGE MODULE46

×

1

EVB-133

P33A3

CELL OVER DISCHARGE MODULE47

×

1

EVB-133

P33A4

CELL OVER DISCHARGE MODULE48

×

1

EVB-133

P33D4

BATTERY INTERNAL RESISTANCE DIAG

×

1

EVB-136

P33D5

CURRENT SENSOR

×

1

EVB-137

P33D6

CURRENT SENSOR

×

1

EVB-139

P33D7

TEMPERATURE SENSOR

—

1

EVB-141

P33D9

TEMPERATURE SENSOR

—

1

EVB-141

P33DD

TEMPERATURE SENSOR

—

1

EVB-141

P33DF

BATT VOLTAGE ISOLATION SEN

×

1

EVB-143

P33E0

BATT VOLTAGE ISOLATION SEN

×

1

EVB-144

P33E1

BATT VOLTAGE ISOLATION SEN

×

1

EVB-145

P33E2

BATT PACK OVER TEMP

×

1

EVB-146

P33E6

CELL CONTROLLER

×

2

EVB-147

P33EB

TEMPERATURE SENSOR

—

1

EVB-154

P33EA

BATTERY HEATER RELAY

×

1

EVB-152

P33ED

BATTERY PARALLEL DIAGNOSIS

×

1

EVB-156

P33EE

BATTERY HEATER CONTROL SYSTEM

×

1

EVB-158

U1000

CAN COMM CIRCUIT

×

1

EVB-160

DTC

CONSULT screen items

EV system

warning

lamp

Trip

Reference

EVB-50

< WIRING DIAGRAM >

VCM

WIRING DIAGRAM
