TRACTION MOTOR INVERTER
TMS-29
< ECU DIAGNOSIS INFORMATION >
D
E
F
G
H
I
J
K
L
M
A
B
TMS
N
O
P
*: These numbers are prescribed by SAE J2012/ISO 15031-6.
DTC
*
Items
(CONSULT screen terms)
EV system warning lamp
Reference
CONSULT
P0A1B
DRIVE MOTOR A CONTROL MODULE
Can illuminate
P0A2C
DRIVE MOTOR A TEMP SENSOR
—
P0A2D
DRIVE MOTOR A TEMP SENSOR
—
P0A2F
DRIVE MOTOR A OVER TEMPERATURE
ON
P0A3F
DRIVE MOTOR A POSITION SENSOR
ON
P0A44
DRIVE MOTOR A OVER SPEED
ON
P0A78
DRIVE MOTOR A INVERTER
ON
P0A8D
14VOLT POWER VOLTAGE
ON
P0BE5
D-MOTOR A PHASE U CURRENT SEN
ON
P0BE6
D-MOTOR A PHASE U CURRENT SEN
ON
P0BE9
D-MOTOR A PHASE V CURRENT SEN
ON
P0BEA
D-MOTOR A PHASE V CURRENT SEN
ON
P0C79
DRIVE MOTOR A INVERTER VOLTAGE
ON
P318E
CAN ERROR
Can illuminate
P3193
CAN ERROR
—
P3197
CAN ERROR
Can illuminate
P3199
CAN ERROR
Can illuminate
P319E
CAN ERROR
—
P31A2
CAN ERROR
Can illuminate
P31A4
CAN ERROR
Can illuminate
P31A9
CAN ERROR
—
P31AD
CAN ERROR
Can illuminate
P3240
DRIVE MOTOR A INVERTER CRNT CONT
ON
P3241
DRIVE MOTOR A INVERTER CRNT CONT
ON
P3242
D-MOTOR A PHASE U CURRENT SEN 2
ON
P3243
D-MOTOR A PHASE V CURRENT SEN 2
ON
P3244
DRIVE MOTOR A INVERTER
—
P3245
DRIVE MOTOR A INVERTER
—
P3247
DRIVE MOTOR A INVERTER
ON
P3249
DRIVE MOTOR A INVERTER
ON
P324A
DRIVE MOTOR A INVERTER VOLTAGE
ON
P324D
DRIVE MOTOR A INVERTER IGBT
ON
P3252
DRIVE MOTOR A INVERTER IGBT
—
P325A
CAN ERROR
—
P325B
DRIVE MOTOR A INVERTER
—
P325C
DRIVE MOTOR A POSITION
ON
P325D
DRIVE MOTOR A POSITION
—
P325E
DRIVE MOTOR A POSITION
—
P325F
DRIVE MOTOR A POSITION
—
U1000
CAN COMM CIRCUIT
—
