DTC P1217 ENGINE OVER TEMPERATURE

EC-443

[KA24DE]

C

D

E

F

G

H

I

J

K

L

M

A

EC

Diagnostic Procedure

UBS00DAO

1.

CHECK COOLING SYSTEM FOR LEAK

Apply pressure to the cooling system with a tester, and check if the
pressure drops.

CAUTION:

Higher than the specified pressure may cause radiator damage.
Pressure should not drop.

OK or NG

OK

>> GO TO 2.

NG

>> Check the following for leak.

●

Hose

●

Radiator

●

Water pump
Refer to

CO-10, "WATER PUMP"

 .

2.

CHECK RADIATOR CAP

Apply pressure to cap with a tester.

OK or NG

OK

>> GO TO 3.

NG

>> Replace radiator cap.

3.

CHECK THERMOSTAT

1.

Check valve seating condition at normal room temperatures.
It should seat tightly.

2.

Check valve opening temperature and valve lift.

3.

Check if valve is closed at 5

°C (9°F) below valve opening tem-

perature.

For details, refer to

CO-13, "THERMOSTAT"

 .

OK or NG

OK

>> GO TO 4.

NG

>> Replace thermostat.

Testing pressure

: 157 kPa (1.6 kg/cm

2

 , 23 psi)

SLC754A

Radiator cap relief
pressure

: 78 - 98 kPa

 (0.8 - 1.0 kg/cm

2

 , 11 - 14 psi)

SLC755A

Valve opening tempera-
ture

: 76.5

°C (170°F) [standard]

Valve lift

: More than 8 mm/90

°C

(0.31 in/194

°F)

SLC343

EC-444

[KA24DE]

DTC P1217 ENGINE OVER TEMPERATURE

4.

CHECK ENGINE COOLANT TEMPERATURE SENSOR

Check resistance as shown in the figure.

<Reference data>

OK or NG

OK

>> GO TO 5.

NG

>> Replace engine coolant temperature sensor.

5.

CHECK MAIN 11 CAUSES

If the cause cannot be isolated, go to

EC-444, "Main 11 Causes of Overheating"

 .

>> INSPECTION END

Perform FINAL CHECK by the following procedure after repair is completed.

1.

Warm up engine. Run the vehicle for at least 20 minutes. Pay attention to engine coolant temperature
gauge on the instrument panel. If the reading shows an abnormally high temperature, another part may be
malfunctioning.

2.

 Stop vehicle and let engine idle. Check the intake and exhaust systems for leaks by listening for noise or
visually inspecting the components.

3.

Allow engine to cool and visually check for oil and coolant leaks. Then, perform “Overall Function Check”.

Main 11 Causes of Overheating

UBS00DAP

SEF152P

Temperature

°C (°F)

Resistance k

Ω

20 (68)

2.1 - 2.9

50 (122)

0.68 - 1.00

90 (194)

0.236 - 0.260

SEF012P

Engine

 Step

Inspection item

Equipment

 Standard

Reference page

OFF

1

●

Blocked radiator

●

Blocked condenser

●

Blocked radiator grille

●

Blocked bumper

●

Visual

No blocking

—

2

●

Coolant mixture

●

Coolant tester

50 - 50% coolant mixture

See

MA-12, "Recom-

mended Fluids and Lubri-
cants"

 .

3

●

Coolant level

●

Visual

Coolant up to MAX level
in reservoir tank and radi-
ator filler neck

See

MA-16

 , “Changing

Engine Coolant”.

4

●

Radiator cap

●

Pressure tester

78 - 98 kPa (0.8 - 1.0 kg/

cm

2

 , 11 - 14 psi)

59 - 98 kPa (0.6 - 1.0 kg/

cm

2

 , 9 - 14 psi) (Limit)

See

CO-8, "System

Check"

 .

DTC P1217 ENGINE OVER TEMPERATURE

EC-445

[KA24DE]

C

D

E

F

G

H

I

J

K

L

M

A

EC

*1: Turn the ignition switch ON.
*2: Engine running at 3,000 rpm for 10 minutes.
*3: Drive at 90 km/h (55 MPH) for 30 minutes and then let idle for 10 minutes.
*4: After 60 minutes of cool down time.
For more information, refer to

CO-6, "OVERHEATING CAUSE ANALYSIS"

 .

ON*

2

5

●

Coolant leaks

●

Visual

No leaks

See

CO-8, "System

Check"

 .

ON*

2

6

●

Thermostat

●

Touch the upper and
lower radiator hoses

Both hoses should be hot

See

CO-13, "THERMO-

STAT"

  and

CO-14,

"RADIATOR"

 .

OFF

7

●

Combustion gas leak

●

Color checker chemi-
cal tester 4 Gas ana-
lyzer

Negative

—

ON*

3

8

●

Coolant temperature
gauge

●

Visual

Gauge less than 3/4
when driving

—

●

Coolant overflow to
reservoir tank

●

Visual

No overflow during driv-
ing and idling

See

MA-16

 , “Changing

Engine Coolant”.

OFF*

4

9

●

Coolant return from
reservoir tank to radia-
tor

●

Visual

Should be initial level in
reservoir tank

See

CO-8, "System

Check"

 .

OFF

10

●

Cylinder head

●

Straight gauge feeler
gauge

0.1 mm (0.004 in) Maxi-
mum distortion (warping)

See

EM-32, "CYLINDER

HEAD"

 .

11

●

Cylinder block and pis-
tons

●

Visual

No scuffing on cylinder
walls or piston

See

EM-48, "CYLINDER

BLOCK"

 .

Engine

 Step

Inspection item

Equipment

 Standard

Reference page

EC-446

[KA24DE]

DTC P1336 CKP SENSOR (OBD)

DTC P1336 CKP SENSOR (OBD)

PFP:23731

Component Description

UBS00DAQ

The crankshaft position sensor (OBD) is located on the transmission
housing facing the gear teeth (cogs) of the flywheel or drive plate. It
detects the fluctuation of the engine revolution.
The sensor consists of a permanent magnet, core and coil.
When the engine is running, the high and low parts of the teeth
cause the gap with the sensor to change.
The changing gap causes the magnetic field near the sensor to
change.
Due to the changing magnetic field, the voltage from the sensor
changes.
The ECM receives the voltage signal and detects the fluctuation of
the engine revolution.
This sensor is not used to control the engine system.
It is used only for the on board diagnosis.

On Board Diagnosis Logic

UBS00DAR

DTC Confirmation Procedure

UBS00DAS

NOTE:
If “DTC Confirmation Procedure” has been previously conducted, always turn ignition switch OFF and wait at
least 5 seconds before conducting the next test.

 WITH CONSULT-II

1.

Turn ignition switch ON and select “DATA MONITOR” mode with
CONSULT-II.

2.

Start engine and run it for at least 2 minutes at idle speed.

3.

If 1st trip DTC is detected, go to

EC-448, "Diagnostic Procedure"

.

 WITH GST

Follow the procedure “WITH CONSULT-II”.

SEF956N

SEF335V

DTC No.

Trouble Diagnosis Name

DTC Detecting Condition

Possible Cause

P1336

Crankshaft position sensor
(OBD) (COG)

●

A chipping of the flywheel or drive plate
gear tooth (cog) is detected by the ECM.

●

Harness or connectors

●

Crankshaft position sensor (OBD)

●

Drive plate/Flywheel

SEF058Y
