HARNESS
A4
M6
W/6
: To E10
B4
M81
L/4
: Off-road lamps relay
A4
M8
BR/12
: To D2
B4
M91
W/16
: To E26
A4
M9
W/16
: To D1
E3
M96
W/20
: AV control unit (with NAVI)
A3
M10
Y/4
: To E29
E3
M97
W/24
: AV control unit (with NAVI)
C3 M13
BR/3
: Front passenger air bag OFF indicator
F3
M98
G/5
: AV control unit (with NAVI)
B2
M14
B/4
: Optical sensor
E2
M105
Y/2
: Front passenger air bag module
E3
M17
W/16
: To B163
E2
M106
O/2
: Front passenger air bag module
B2
M18
W/40
: BCM (body control module)
A2
M109
BR/2
: Front tweeter LH
B3
M19
W/15
: BCM (body control module)
E1
M111
BR/2
: Front tweeter RH
B3
M20
B/15
: BCM (body control module)
E2
M120
W/4
: Remote keyless entry receiver
C4 M21
W/4
: NATS antenna amp.
E2
M121
W/4
: Variable blower control
C3 M22
W/16
: Data link connector
C4
M123
W/2
: Tire pressure warning check connector
B2
M24
W/40
: Combination meter
D4
M141
GR/8
: 4WD shift switch
B3
M26
W/6
: Ignition switch
C2
M142
B/6
: Mode door motor
B3
M27
W/2
: Key switch
D3
M146
GR/2
: Intake sensor
C3 M28
W/16
: Combination switch
D2
M147
B/6
: Air mix door motor
C4 M29
Y/6
: Combination switch (spiral cable)
D3
M149
W/6
: Differential lock mode switch
C4 M30
GR/8
: Combination switch (spiral cable)
C3
M150
W/2
: Ignition keyhole illumination
F2
M31
SMJ
: To E152
C2
M151
G/20
: Joint connector-M03
E5
M35
Y/28
: Air bag diagnosis sensor unit
A3
M152
W/26
: Transfer control unit
F3
M36
SMJ
: To B149
B4
M153
W/24
: Transfer control unit
A4
M40
SMJ
: To B69
D4
M154
GR/6
: VDC OFF switch
E3
M43
W/20
: Audio unit (with base audio system)
D4
M155
W/8
: Hill descent control switch
E2
M44
W/20
: Audio unit (with display audio system)
D4
M156
W/10
: A/T shift selector
D3 M45
W/32
: Audio unit (with display audio system)
B4
M159
W/16
: Door mirror remote control switch
C4 M47
W/8
: Steering angle sensor
E3
M160
BR/6
: Front heated seat switch RH
D2 M50
B/26
: Front air control
D4
M161
W/6
: Front heated seat switch LH
E3
M52
W/16
: Audio unit (with base audio system)
B3
M163
W/8
: Clutch interlock cancel switch
E3
M53
B/3
: Lower front power socket
D1
M166
L/20
: Joint connector-M01
D4 M54
GR/3
: Upper front power socket
D1
M167
L/20
: Joint connector-M02
C3 M55
W/4
: Hazard switch
A3
M168
L/4
: Accessory relay-2
B3
M57
—
: Body ground
C3
M169
L/7
: To M205
E2
M58
B/6
: Intake door motor
C4
M170
B/2
: Resistor
D2 M61
—
: Body ground
Console sub-harness
E2
M62
B/2
: Front blower motor
E4
M204
W/6
: To M63
D4 M63
W/6
: To M204
C3
M205
L/7
: To M169
F3
M64
G/5
: Audio unit (with display audio system)
F5
M207
B/3
: Console power socket
B4
M70
W/26
: Differential lock control unit
C3
M214
L/5
: USB interface
F2
M74
W/16
: To D151
D5
M215
W/4
: Aux in jack
F2
M75
W/12
: To D153
