PCS IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM) PCS-27 < UNIT REMOVAL AND INSTALLATION > [IPDM E/R] C D E F G H I J K L B A O P N UNIT REMOVAL AND INSTALLATION IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE Removal and Installation INFOID:0000000009483734 REMOVAL CAUTION: Do not remove the relays from the IPDM E/R. Tampering with the relays may cause additional incidents with the vehicle. PG-72, "Removal and Installation" 2. Remove IPDM E/R upper cover. 3. Release two clips and pull IPDM E/R up from case. remove. INSTALLATION Installation is in the reverse order of removal. WKIA3352E LKIA0421E |
