EC-394 < DTC/CIRCUIT DIAGNOSIS > [VQ40DE] P1554 BATTERY CURRENT SENSOR 2. Also check harness for short to ground and short to power. OK >> GO TO 8. NG >> GO TO 7. 7. DETECT MALFUNCTIONING PART Check the following. • Harness connectors E5, F14 • Harness for open or short between battery current sensor and ECM >> Repair open circuit or short to ground or short to power in harness or connectors. 8. CHECK BATTERY CURRENT SENSOR EC-394, "Component Inspection" OK or NG OK >> GO TO 9. NG >> Replace battery negative cable assembly. 9. CHECK INTERMITTENT INCIDENT GI-40, "Intermittent Incident" >> INSPECTION END Component Inspection INFOID:0000000009484134 BATTERY CURRENT SENSOR 1. Reconnect harness connectors disconnected. ground. 4. Turn ignition switch ON. signal) and ground. 6. If NG, replace battery negative cable assembly. Continuity should exist. Voltage: Approximately 2.5V BBIA0588E |
