HAC-50 < DTC/CIRCUIT DIAGNOSIS > [AUTOMATIC AIR CONDITIONER] SUNLOAD SENSOR Is the inspection result normal? YES >> Replace the A/C auto amp. NO >> Repair the harnesses or connectors. Component Inspection INFOID:0000000006024034 1. CHECK SUNLOAD SENSOR 1. Turn the ignition switch ON. 2. Check the input voltage from sunload sensor between A/C auto amp. harness connector and the ground. NOTE: sensor to check. • The sunload amount produced by direct sunshine in fair weather is equivalent to approximately 0.77 kW/m 2 (662 kcal/m 2 ·h). Is the inspection result normal? YES >> INSPECTION END NO >> Replace the sunload sensor. Sunload sensor — Continuity Connector Terminal M74 1 Ground Not existed (+) ( − ) A/C auto amp. — Connector Terminal M50 18 Ground JPIIA1659GB |
