EM-98

< SERVICE DATA AND SPECIFICATIONS (SDS)

[HR12DE]

SERVICE DATA AND SPECIFICATIONS (SDS)

Available Piston

Unit: mm (in)

Piston Ring

Unit: mm (in)

Piston Pin

Unit: mm (in)

Connecting Rod

Cylinder block main bearing housing inner diameter grade

Grade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No. F
Grade No. G
Grade No. H
Grade No. J
Grade No. K
Grade No. L
Grade No. M
Grade No. N
Grade No. P
Grade No. R
Grade No. S
Grade No. T
Grade No. U
Grade No. V
Grade No. W

51.997 - 51.998 (2.0471 - 2.0472)
51.998 - 51.999 (2.0472 - 2.0472)
51.999 - 52.000 (2.0472 - 2.0472)
52.000 - 52.001 (2.0472 - 2.0472)
52.001 - 52.002 (2.0473 - 2.0473)
52.002 - 52.003 (2.0473 - 2.0473)
52.003 - 52.004 (2.0474 - 2.0474)
52.004 - 52.005 (2.0474 - 2.0474)
52.005 - 52.006 (2.0474 - 2.0474)
52.006 - 52.007 (2.0475 - 2.0475)
52.007 - 52.008 (2.0475 - 2.0475)
52.008 - 52.009 (2.0476 - 2.0476)
52.009 - 52.010 (2.0476 - 2.0476)

52.010 - 52.011 (2.0476 - 2.0476)
52.011 - 52.012 (2.0477 - 2.0477)

52.012 - 52.013 (2.0477 - 2.0477)
52.013 - 52.014 (2.0478 - 2.0478)
52.014 - 52.015 (2.0478 - 2.0478)
52.015 - 52.016 (2.0478 - 2.0478)
52.016 - 52.017 (2.0479 - 2.0479)

Difference in inner diameter between cylinders

Standard

Less than 0.03 (0.0012)

Piston skirt diameter “A”

77.965 - 77.980 (3.0694 - 3.0700)

Piston height “H” dimension

37.1 (1.460)

Piston pin hole diameter

19.006 - 19.012 (0.7482 - 0.7485)

Piston to cylinder bore clearance

0.020 - 0.050 (0.0007 - 0.0019)

PBIC0188E

Items

Standard

Limit

Side clearance

Top

0.040 - 0.080 (0.0015 - 0.0031)

0.11 (0.0043)

2nd

0.030 - 0.070 (0.0012 - 0.0028)

0.10 (0.0039)

Oil (rail ring)

0.045 - 0.125 (0.0017 - 0.0049)

End gap

Top

0.20 - 0.30 (0.0078 - 0.0118)

0.50 (0.0196)

2nd

0.35 - 0.50 (0.0137 - 0.0196)

0.66 (0.0259)

Oil (rail ring)

0.20 - 0.60 (0.0079 - 0.0236)

0.92 (0.0362)

Piston pin outer diameter

18.996 - 19.002 (0.7478 - 0.7481)

Piston to piston pin oil clearance

Standard

0.008 - 0.012 (0.0003 - 0.0004)

Connecting rod bushing oil clearance

Standard

–0.018 to –0.044 (–0.0007 to –0.0017)

SERVICE DATA AND SPECIFICATIONS (SDS)

EM-99

< SERVICE DATA AND SPECIFICATIONS (SDS)

[HR12DE]

C

D

E

F

G

H

I

J

K

L

M

A

EM

N

P

O

Unit: mm (in)

*: After installing in connecting rod

Main Bearing

INFOID:0000000005988227

MAIN BEARING

Unit: mm (in)

Center distance

129.84 - 129.94 (5.1118 - 5.1157)

Bend [per 100 (3.94)]

Limit

0.15 (0.0059)

Torsion [per 100 (3.94)]

Limit

0.30 (0.0118)

Connecting rod bushing inner diameter*

18.958 - 18.978 (0.7463 - 0.7471)

Side clearance

Standard

0.200 - 0.352 (0.0079 - 0.0138)

Connecting rod big end diameter

Grade No. A
Grade No. B
Grade No. C
Grade No. D
Grade No. E
Grade No. F
Grade No. G
Grade No. H
Grade No. J
Grade No. K
Grade No. L
Grade No. M
Grade No. N

43.000 - 43.001 (1.6929 - 1.6929)
43.001 - 43.002 (1.6929 - 1.6930)
43.002 - 43.003 (1.6930 - 1.6930)
43.003 - 43.004 (1 6930 - 1.6931)
43.004 - 43.005 (1.6931 - 1.6931)
43.005 - 43.006 (1.6931 - 1.6931)
43.006 - 43.007 (1.6931 - 1.6932)
43.007 - 43.008 (1.6932 - 1.6932)
43.008 - 43.009 (1.6932 - 1.6933)
43.009 - 43.010 (1.6933 - 1.6933)

43.010 - 43.011 (1.6933 - 1.6933)
43.011 - 43.012 (1.6933 - 1.6934)

43.012 - 43.013 (1.6934 - 1.6934)

Grade number

Thickness

Identification color

Remarks

0

1.996 - 1.999 (0.0785 - 0.0787)

Black

Grade and color are the same
for upper and lower bearings.

1

1.999 - 2.002 (0.0787 - 0.0788)

Brown

2

2.002 - 2.005 (0.0788 - 0.0789)

Green

3

2.005 - 2.008 (0.0789 - 0.0790)

Yellow

4

2.008 - 2.011 (0.0790 - 0.0791)

Blue

5

2.011 - 2.014 (0.0791 - 0.0792)

Pink

SEM685D

EM-100

< SERVICE DATA AND SPECIFICATIONS (SDS)

[HR12DE]

SERVICE DATA AND SPECIFICATIONS (SDS)

Undersize

Unit: mm (in)

Bearing Oil Clearance

Unit: mm (in)

Connecting Rod Bearing

INFOID:0000000005988228

CONNECTING ROD BEARING

Unit: mm (in)

01

UPR

1.996 - 1.999 (0.0785 - 0.0787)

Black

Grade and color are different
for upper and lower bearings.

LWR

1.999 - 2.002 (0.0787 - 0.0788)

Brown

12

UPR

1.999 - 2.002 (0.0787 - 0.0788)

Brown

LWR

2.002 - 2.005 (0.0788 - 0.0789)

Green

23

UPR

2.002 - 2.005 (0.0788 - 0.0789)

Green

LWR

2.005 - 2.008 (0.0789 - 0.0790)

Yellow

34

UPR

2.005 - 2.008 (0.0789 - 0.0790)

Yellow

LWR

2.008 - 2.011 (0.0790 - 0.0791)

Blue

45

UPR

2.008 - 2.011 (0.0790 - 0.0791)

Blue

LWR

2.011 - 2.014 (0.0791 - 0.0792)

Pink

Grade number

Thickness

Identification color

Remarks

SEM685D

Items

Thickness

Main journal diameter

US 0.25 (0.0098)

2.126 - 2.134 (0.0837 - 0.0840)

Grind so that bearing clearance is the specified value.

Main bearing oil clearance

Standard

0.024 - 0.034 (0.0009 - 0.0013)

Grade number

Thickness

Identification color

Remarks

0

1.498 - 1.501 (0.0590 - 0.0591)

Black

Grade and color are the same
for upper and lower bearings.

1

1.501 - 1.504 (0.0591 - 0.0592)

Brown

2

1.504 - 1.507 (0.0592 - 0.0593)

Green

3

1.507 - 1.510 (0.0593 - 0.0594)

Yellow

4

1.510 - 1.513 (0.0594 - 0.0596)

Blue

01

UPR

1.498 - 1.501 (0.0590 - 0.0591)

Black

Grade and color are different
between upper and lower bear-
ings.

LWR

1.501 - 1.504 (0.0591 - 0.0592)

Brown

12

UPR

1.501 - 1.504 (0.0591 - 0.0592)

Brown

LWR

1.504 - 1.507 (0.0592 - 0.0593)

Green

23

UPR

1.504 - 1.507 (0.0592 - 0.0593)

Green

LWR

1.507 - 1.510 (0.0593 - 0.0594)

Yellow

34

UPR

1.507 - 1.510 (0.0593 - 0.0594)

Yellow

LWR

1.510 - 1.513 (0.0594 - 0.0596)

Blue

SERVICE DATA AND SPECIFICATIONS (SDS)

EM-101

< SERVICE DATA AND SPECIFICATIONS (SDS)

[HR12DE]

C

D

E

F

G

H

I

J

K

L

M

A

EM

N

P

O

Undersize

Unit: mm (in)

Bearing Oil Clearance

Unit: mm (in)

Items

Thickness

Crankshaft pin journal diameter

US 0.25 (0.0098)

1.627 - 1.635 (0.0640 - 0.0644)

Grind so that bearing clearance is the specified value.

Connecting rod bearing oil clearance

Standard

 0.029 - 0.039 (0.0011 - 0.0015)

Limit

0.10 (0.0039)
