PREPARATION

BR-5

< PREPARATION >

C

D

E

G

H

I

J

K

L

M

A

B

BR

N

O

P

PREPARATION

PREPARATION

Commercial Service Tool

INFOID:0000000005986566

Tool name

Description

Brake pressure gauge

Check brake fluid pressure

Handy vacuum pump

• Air tight
• Inspection of check valve

Brake caliper wrench

Return the piston

S-NT151

ZZC1313D

NNFIA0040ZZ

B

R

- 6

< SYMPTOM DIAGNOSIS >

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

SYMPTOM DIAGNOSIS

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NVH Troubleshooting Chart

INFOID:0000000005986561

Use the chart below to find the cause of the symptom. If necessary, repair or replace these parts.

×

: Applicable

Reference page

BR-13

BR-15

BR-13

BR-15

BR

-3

4

BR

-1

3

BR-13

BR-15

BR

-1

3

BR

-1

3

BR-13

BR-15

BR-13

BR-15

BR

-1

3

BR

-1

5

NV

in

 F

A

X

, R

A

X

 a

n

d

 FS

U,

 R

S

U

 s

e

c

tio

n

NV

in

 WT s

e

cti

o

n

NV

in

 WT s

e

cti

o

n

NV

in

 F

A

X

 se

ct

ion

NV

in

 S

T

 s

e

c

ti

o

n

Possible cause and
SUSPECTED PARTS

P

a

d

s

 o

r li

ni

ng

 da

ma

ge

d

P

a

d

s

 o

r li

ni

ng

 un

ev

en

 wea

r

S

h

im

s

 da

ma

ge

d

Ro

to

r im

ba

lan

c

e

Ro

to

r or

drum

 d

a

m

a

g

e

Rotor runout

Ro

to

r de

form

a

tio

n

Ro

to

r or

drum

 d

e

fl

ec

tio

n

Ro

to

r or

drum

 ru

st

Ro

to

r th

ickne

s

s vari

ati

o

n

Dru

m

 ou

t o

f ro

und

A

X

LE AND

SUSPENSI

ON

TI

RE

ROAD W

H

EEL

DRIV

E

 SHAFT

S

T

EERING

Symptom

BRAKE

Noise

×

×

×

×

×

×

×

×

Shake

×

×

×

×

×

×

Shimmy, Judder

×

×

×

×

×

×

×

×

×

×

×

BRAKE PEDAL

BR-7

< PERIODIC MAINTENANCE >

C

D

E

G

H

I

J

K

L

M

A

B

BR

N

O

P

PERIODIC MAINTENANCE

BRAKE PEDAL

Inspection and Adjustment

INFOID:0000000005986567

INSPECTION

Brake Pedal Height

Check the height (H

1

) between the dash lower panel (1) and the

brake pedal upper surface.

CAUTION:

Remove the floor trim.

Stop Lamp Switch

Check the clearance (C) among the brake pedal lever (1) and the
stop lamp switch (2) threaded end.

CAUTION:

The stop lamp must turn off when the brake pedal is released.
NOTE:
Pull the brake pedal pad to make the clearance between the stop
lamp switch threaded end and the brake peal lever.

Brake Pedal Play

Press the brake pedal. Check the brake pedal play (A) (stroke until
fluid pressure occurs).

Depressed Brake Pedal Height

Check the height between the dash lower panel (1) and the brake
pedal upper surface (H

2

) when depressing the brake pedal at 490 N

(50 kg, 110 lb) while turning engine ON.

CAUTION:

Remove the floor trim.

ADJUSTMENT

H

1

: Refer to

BR-42, "Brake Pedal"

.

JPFIA0065ZZ

C

: Refer to

BR-42, "Brake Pedal"

.

PFIA0813J

A

:  Refer  to

BR-42, "Brake Pedal"

.

JPFIA0277ZZ

H

2

: Refer to

BR-42, "Brake Pedal"

.

JPFIA0068ZZ

BR-8

< PERIODIC MAINTENANCE >

BRAKE PEDAL

Brake Pedal Height

1.

Remove instrument lower panel LH. Refer to

IP-13, "Removal and Installation"

.

2.

Disconnect the harness connector from stop lamp switch.

3.

Loosen the stop lamp switch 45

°

 counterclockwise.

4.

Adjust the brake pedal height with the following procedure.

a.

Loosen the input rod lock nut (1).

CAUTION:

The threaded end of the input rod (2) must project to the
inner side (L) of the clevis (3).

b.

Rotate the input rod, adjust the brake pedal to the specified
height (H

1

).

c.

Tighten the lock nut. Refer to

BR-28, "Exploded View"

.

5.

Check the brake pedal play.

Brake Pedal Play

NOTE:
The clearance between the stop lamp switch threaded end and the brake pedal lever is adjusted by adjusting
play of the brake pedal.

1.

Remove instrument lower panel LH. Refer to

IP-13, "Removal and Installation"

.

2.

Disconnect the harness connector from stop lamp switch.

3.

Loosen the stop lamp switch 45

°

 counterclockwise.

4.

Press-fit the stop lamp switch (2) until the stop lamp switch hits
the brake pedal lever (1) 45

°

 clockwise while pulling the brake

pedal pad slightly.

CAUTION:

• The clearance (C) between the brake pedal lever and stop

lamp switch threaded and must be the specified value.

• The stop lamp must be turned off when the brake pedal is

released.

JPFIA0003ZZ

H

1

: Refer to

BR-42, "Brake Pedal"

.

JPFIA0279ZZ

C

: Refer to

BR-42, "Brake Pedal"

.

PFIA0813J
