INTELLIGENT KEY UNIT
DLK-135
< ECU DIAGNOSIS INFORMATION >
[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
M
A
B
DLK
N
O
P
Reference Value - Steering Lock Solenoid
INFOID:0000000007355516
TERMINAL LAYOUT
PHYSICAL VALUES
29
GR
Back door request
switch
—
Back door request switch ON.
0
Back door request switch OFF.
5
30
W
Remote keyless en-
try receiver power
supply
—
—
5
32
V
Steering lock sole-
noid communication
signal
LOCK
When Intelligent Key is inside vehicle,
press ignition knob switch.
Other than above
5
33
G
Center console area
antenna (+) signal
LOCK
Any door open
→
all doors closed
34
R
Center console area
antenna (-) signal
37
P
Front outside anten-
na (+) signal RH
LOCK
Press front door request switch RH.
38
V
Front outside anten-
na (-) signal RH
39
SB
P range switch
—
Selector lever is in “P” position.
0
Other than above
Battery voltage
40
R
AS select unlock out-
put
—
UNLOCK with rear door locks disabled.
0
Other than above
Battery voltage
Terminal
Wire
Color
Item
Condition
Voltage (V)
Approx.
Ignition
Switch Po-
sition
Operation or Conditions
SIIA1911J
PIIB7441E
SIIA1910J
WIIA1169E
