AV-298 < SYSTEM DESCRIPTION > [BOSE AUDIO WITH NAVIGATION] DIAGNOSIS SYSTEM (AV CONTROL UNIT) Area with yellow connection lines Description Possible malfunction location / Action to take AV control unit malfunction is detect- Replace the AV control unit. Refer to AV-420, "Removal and Installation" Poor connection is detected for the • Harness or connector. Switch malfunction is detected. Perform A/C and AV switch assembly AND AV SWITCH ASSEMBLY : Com- . Poor connection is detected for the • Harness or connector. AWNIA2280GB AWNIA2281GB AWNIA2282GB AWNIA2283GB August 2012 2012 Pathfinder |
