PWO-8 < REMOVAL AND INSTALLATION > POWER SOCKET REMOVAL AND INSTALLATION POWER SOCKET Removal and Installation INFOID:0000000006243571 UPPER AND LOWER FRONT POWER SOCKET, CONSOLE POWER SOCKET, AND REAR CAR- NOTE: If the tool does not fit because of the location of the power socket, further disassembly may be required. Refer to IP-22, "Disassembly and Assembly" (Center Console), or 25, "Removal and Installation" (Luggage Floor Trim). Removal 1. Remove the fuse for the power socket. the power socket. 3. Lift up the handle of the Tool until the other end of the Tool is inside the socket and snaps into the other square hole in the power socket. 4. Pull the power socket straight out with the Tool. 5. Disconnect power socket connector. Installation Installation is in the reverse order of removal. NOTE: Make sure to align the tab with the square notched area during installation. Tool number: — (J-42059) AWMIA1182GB WKIA1035E AWMIA1183GB 2011 Pathfinder |
