DEF-16 < DTC/CIRCUIT DIAGNOSIS > DOOR MIRROR DEFOGGER LH Check continuity between door mirror LH harness connector D4 (without ADP), D18 (with ADP) terminal 6 and ground. Is the inspection result normal? YES >> GO TO 6 NO >> Repair or replace harness. 6. CHECK DOOR MIRROR DEFOGGER LH Check door mirror defogger LH. DEF-16, "Component Inspection" Is the inspection result normal? YES >> GO TO 7 NO >> Replace door mirror. Refer to MIR-16, "Door Mirror Assembly" . 7. CHECK INTERMITTENT INCIDENT Check intermittent incident. GI-37, "Intermittent Incident" Is the inspection result normal? YES >> Check the following. • Battery power supply circuit. • IPDM E/R. NO >> Repair or replace the malfunctioning parts. Component Inspection INFOID:0000000006247595 1. CHECK DOOR MIRROR DEFOGGER Check continuity between door mirror LH terminals 1 and 6. Is the inspection result normal? YES >> Check the condition of the harness and the connector. NO >> Replace malfunctioning door mirror LH. Refer to . 6 - Ground : Continuity should exist. LIIA2037E 1 - 6 : Continuity should exist. AWLIA1760ZZ 2011 Pathfinder |
