AV DIAGNOSIS SYSTEM (AV CONTROL UNIT) AV-299 < SYSTEM DESCRIPTION > [BOSE AUDIO WITH NAVIGATION] C D E F G H I J K L M B A O P CONFIRMATION/ADJUSTMENT MODE 1. Start the diagnosis function and select “Confirmation/Adjustment”. The confirmation/adjustment mode indicates where each item can be checked or adjusted. 2. Select each item on the “Confirmation/Adjustment” mode screen to display the relevant trouble diagnosis screen. Touch “BACK” on the display or press the “BACK” button to return to the initial Confirmation/Adjustment Mode screen. Poor connection is detected for the • Harness or connector. Poor connection is detected for the • Harness or connector. Area with yellow connection lines Description Possible malfunction location / Action to take AWNIA2284GB AWNIA2285GB ALNIA0218GB 2011 Pathfinder |
