EC-948

< SYMPTOM DIAGNOSIS >

[VK56DE]

ENGINE CONTROL SYSTEM SYMPTOMS

1 - 6: The numbers refer to the order of inspection.
(continued on next table)

SYSTEM — ENGINE MECHANICAL & OTHER

Mass air flow sensor circuit

1

1

2

2

2

2

2

2

EC-597
EC-603

Engine coolant temperature sensor circuit

3

3

3

EC-611
EC-615

Air fuel ratio (A/F) sensor 1 circuit

EC-630
EC-634
EC-638



EC-642



EC-861

Throttle position sensor circuit

2

2

EC-618
EC-682



EC-801



EC-803



EC-853

Accelerator pedal position sensor circuit

3

2

1

EC-784
EC-846



EC-849



EC-857

Knock sensor circuit

2

3

EC-693

Crankshaft position sensor (POS) circuit

2

2

EC-696

Camshaft position sensor (PHASE) circuit

3

2

EC-700

Vehicle speed signal circuit

2

3

3

3

EC-770

Power steering pressure sensor circuit

2

3

3

EC-776

ECM

2

2

3

3

3

3

3

3

3

3

3

EC-779
EC-781
EC-783

Intake valve timing control solenoid valve cir-
cuit

3

2

1

3

2

2

3

3

EC-594

Park/neutral position (PNP) signal circuit

3

3

3

3

3

EC-787

Refrigerant pressure sensor circuit

2

3

3

4

EC-893

Electrical load signal circuit

3

EC-873

Air  conditioner  circuit

2

2

3

3

3

3

3

3

3

3

2

HAC-4

 or

HAC-122

ABS actuator and electric unit (control unit)

4

EC-796



SYMPTOM

Refer-
ence page

HARD/NO S

TA

R

T/RES

TA

R

T (E

XCP

. HA)

E

N

GINE

 ST

ALL

HES

IT

A

TION/SURGING/FLA

T

 SPOT

S

P

ARK KNOC

K

/DET

O

NA

TI

ON

LACK OF

POWER/POOR ACCELERA

TION

HIG

H

 IDL

E

/L

OW

 ID

LE

ROUGH IDLE/HUNTING

ID

LING VI

BRA

T

ION

S

LOW/NO RETU

RN

T

O ID

LE

OVERHEA

T

S

/W

A

TER TEMPERA

T

URE HIG

H

E

XCESSIVE

 FUEL CON

S

UMP

T

ION

E

XCESSIVE

 OIL

C

O

NSUMP

T

ION

B

A

TTER

Y

DEAD (UNDER CHARGE)

Warranty symptom code

AA

AB

AC

AD

AE

AF AG AH

AJ

AK

AL

AM HA

2010 Pathfinder

ENGINE CONTROL SYSTEM SYMPTOMS

EC-949

< SYMPTOM DIAGNOSIS >

[VK56DE]

C

D

E

F

G

H

I

J

K

L

M

A

EC

N

P

O

SYMPTOM

Reference
page

HARD/NO ST

AR

T/REST

AR

T (EXCP

.

HA)

E

N

GI

N

E

 ST

AL

L

HESIT

A

TION/S

U

R

GING/F

LA

T SP

OT

SP

ARK KNOCK/DE

T

O

NA

TION

LACK OF POWE

R/POOR

 ACCELERA

TIO

N

HIGH IDL

E/L

OW

 IDL

E

ROUG

H IDLE/HU

NTING

IDL

ING VIBRA

T

ION

SLO

W

/NO RETURN T

O

 IDLE

OVERHEA

T

S/W

A

TE

R

 TEMPERA

T

URE

HIGH

EXCES

SIVE F

U

EL CONSUMP

T

ION

EXCES

SIVE OI

L CONSUMP

T

IO

N

BA

TTE

R

Y

DEAD (UN

D

E

R

 CH

A

R

GE)

Warranty symptom code

AA

AB

AC

AD

AE

AF

AG AH

AJ

AK

AL

AM HA

Fuel

Fuel tank

5

5

FL-6

Fuel piping

5

5

5

5

5

5

FL-5

Vapor lock

—

Valve deposit

5

5

5

5

5

5

5

—

Poor fuel (Heavy weight gasoline,
Low octane)

—

Air

Air duct

5

5

5

5

5

5

EM-161

Air cleaner

EM-161

Air leakage from air duct
(Mass air flow sensor — electric
throttle control actuator)

5

5

5

5

EM-161

Electric throttle control actuator

EM-162

Air leakage from intake manifold/
Collector/Gasket

EM-162

Cranking

Battery

1

1

1

1

1

1

1

1

PG-5

Generator circuit

CHG-5

Starter circuit

3

STR-5

Signal plate

6

EM-189

Park/neutral position (PNP) sig-
nal

4

TM-50

Engine

Cylinder head

5

5

5

5

5

5

5

5

EM-204

Cylinder head gasket

4

3

Cylinder block

6

6

6

6

6

6

6

6

4

EM-219

Piston

Piston ring

Connecting rod

Bearing

Crankshaft

Valve
mecha-
nism

Timing chain

5

5

5

5

5

5

5

5

EM-181

Camshaft

EM-189

Intake valve timing control

EM-181

Intake valve

3

EM-204

Exhaust valve

2010 Pathfinder

EC-950

< SYMPTOM DIAGNOSIS >

[VK56DE]

ENGINE CONTROL SYSTEM SYMPTOMS

1 - 6: The numbers refer to the order of inspection.

Exhaust

Exhaust manifold/Tube/Muffler/
Gasket

5

5

5

5

5

5

5

5

EM-166

Three way catalyst

Lubrica-
tion

Oil pan/Oil strainer/Oil pump/Oil
filter/Oil gallery/Oil cooler

5

5

5

5

5

5

5

5

LU-27
LU-28



LU-30



LU-34

Oil level (Low)/Filthy oil

LU-24

Cooling

Radiator/Hose/Radiator filler cap

5

5

5

5

5

5

5

4

5

CO-46

Thermostat

5

CO-53

Water pump

CO-51

Water gallery

CO-35

Cooling fan

5

CO-48
CO-49

Coolant level (Low)/Contaminat-
ed coolant

5

CO-39

NVIS (NISSAN Vehicle Immobilizer System —
NATS)

1

1

SEC-5

 or

SEC-120

SYMPTOM

Reference
page

HARD/NO S

TA

R

T/RES

TA

R

T (E

XCP

. HA)

E

N

GINE

 ST

ALL

HES

IT

A

TION/SURGING/FLA

T

 SPOT

S

P

ARK KNOC

K

/DET

O

NA

TI

ON

LACK OF

POWER/POOR ACCELERA

TION

HIG

H

 IDL

E

/L

OW

 ID

LE

ROUGH IDLE/HUNTING

ID

LING VI

BRA

T

ION

S

LOW/NO RETU

RN

T

O ID

LE

OVERHEA

T

S

/W

A

TER TEMPERA

T

URE HIG

H

E

XCESSIVE

 FUEL CON

S

UMP

T

ION

E

XCESSIVE

 OIL

C

O

NSUMP

T

ION

B

A

TTER

Y

DEAD (UNDER CHARGE)

Warranty symptom code

AA

AB

AC

AD

AE

AF

AG AH

AJ

AK

AL

AM HA

2010 Pathfinder

NORMAL OPERATING CONDITION

EC-951

< SYMPTOM DIAGNOSIS >

[VK56DE]

C

D

E

F

G

H

I

J

K

L

M

A

EC

N

P

O

NORMAL OPERATING CONDITION

Fuel Cut Control (at No Load and High Engine Speed)

INFOID:0000000005257922

INPUT/OUTPUT SIGNAL CHART

*: This signal is sent to the ECM via the CAN communication line.

SYSTEM DESCRIPTION

If the engine speed is above 2,400 rpm under no load (for example, the selector lever position is neutral and

engine speed over is 2,400 rpm) fuel will be cut off after some time. The exact time when the fuel is cut off var-

ies based on engine speed.

Fuel cut will be operated until the engine speed reaches 1,000 rpm, then fuel cut will be cancelled.

NOTE:

This function is different from deceleration control listed under

EC-522, "System Description"

.

Sensor

Input signal to ECM

ECM function

Actuator

Accelerator pedal position sensor

Accelerator pedal position

Fuel cut control Fuel injector

Engine coolant temperature sensor

Engine coolant temperature

Crankshaft position sensor (POS)
Camshaft position sensor (PHASE)

Engine speed

Unified meter control unit

Neutral position

Vehicle speed*

2010 Pathfinder

EC-952

< PRECAUTION >

[VK56DE]

PRECAUTIONS

PRECAUTION

PRECAUTIONS

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"

INFOID:0000000005257923

The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along

with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain

types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS

system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front

air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.

Information necessary to service the system safely is included in the SRS and SB section of this Service Man-

ual.

WARNING:

• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in

the event of a collision which would result in air bag inflation, all maintenance must be performed by

an authorized NISSAN/INFINITI dealer.

• Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal

injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag

Module, see the SRS section.

• Never use electrical test equipment on any circuit related to the SRS unless instructed to in this Ser-

vice Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or harness

connectors.

On Board Diagnosis (OBD) System of Engine and A/T

INFOID:0000000005257924

The ECM has an on board diagnostic system. It will illuminate the malfunction indicator lamp (MIL) to warn the

driver of a malfunction causing emission deterioration.

CAUTION:

• Always turn the ignition switch OFF and disconnect the negative battery cable before any repair or

inspection work. The open/short circuit of related switches, sensors, solenoid valves, etc. will cause

the MIL to illuminate.

• Always connect and lock the connectors securely after work. A loose (unlocked) connector will

cause the MIL to illuminate due to the open circuit. (Check that the connector is free from water,

grease, dirt, bent terminals, etc.)

• Certain systems and components, especially those related to OBD, may use a new style slide-lock-

ing type harness connector. For description and how to disconnect, refer to

PG-68, "Description"

.

• Always route and secure the harnesses properly after work. The interference of the harness with a

bracket, etc. may cause the MIL to illuminate due to the short circuit.

• Always connect rubber tubes properly after work. A misconnected or disconnected rubber tube may

cause the MIL to illuminate due to the malfunction of the EVAP system or fuel injection system, etc.

• Always erase the unnecessary malfunction information (repairs completed) from the ECM and TCM

(Transmission control module) before returning the vehicle to the customer.

Precaution

INFOID:0000000005257925

•

Always use a 12 volt battery as power source.

•

Never attempt to disconnect battery cables while engine is

running.

•

Before connecting or disconnecting the ECM harness con-

nector, turn ignition switch OFF and disconnect negative bat-

tery cable. Failure to do so may damage the ECM because

battery voltage is applied to ECM even if ignition switch is

turned OFF.

•

Before removing parts, turn ignition switch OFF and then dis-

connect negative battery cable.

SEF289H

2010 Pathfinder

PRECAUTIONS

EC-953

< PRECAUTION >

[VK56DE]

C

D

E

F

G

H

I

J

K

L

M

A

EC

N

P

O

•

Never disassemble ECM.

•

If a battery cable is disconnected, the memory will return to

the ECM value.

The ECM will now start to self-control at its initial value. Thus,

engine operation can vary slightly in this case. However, this

is not an indication of a malfunction. Never replace parts

because of a slight variation.

•

If the battery is disconnected, the following emission-related

diagnostic information will be cleared within 24 hours.

-

Diagnostic trouble codes

-

1st trip diagnostic trouble codes

-

Freeze frame data

-

1st trip freeze frame data

-

System readiness test (SRT) codes

-

Test values

•

When connecting ECM harness connector, fasten it securely

with a lever as far as it will go as shown in the figure.

•

When connecting or disconnecting pin connectors into or

from ECM, never damage pin terminals (bends or breaks).

Check that there are not any bends or breaks on ECM pin ter-

minal, when connecting pin connectors.

•

Securely connect ECM harness connectors.

A poor connection can cause an extremely high (surge) volt-

age to develop in coil and condenser, thus resulting in dam-

age to ICs.

•

Keep engine control system harness at least 10 cm (4 in) away

from adjacent harness, to prevent engine control system mal-

functions due to receiving external noise, degraded operation

of ICs, etc.

•

Keep engine control system parts and harness dry.

•

Before replacing ECM, perform ECM Terminals and Reference

Value inspection and check that ECM functions properly.

Refer to

EC-899, "ECM Terminal and Reference Value"

.

•

Handle mass air flow sensor carefully to avoid damage.

•

Never disassemble mass air flow sensor.

•

Never clean mass air flow sensor with any type of detergent.

•

Never disassemble electric throttle control actuator.

•

Even a slight leakage in the air intake system can cause seri-

ous incidents.

•

Never shock or jar the camshaft position sensor (PHASE),

crankshaft position sensor (POS).

PBIB1164E

PBIB1512E

PBIB0090E

MEF040D

2010 Pathfinder

EC-954

< PRECAUTION >

[VK56DE]

PRECAUTIONS

•

After performing each TROUBLE DIAGNOSIS, perform DTC

Confirmation Procedure or Overall Function Check.

The DTC should not be displayed in the DTC Confirmation

Procedure if the repair is completed. The Overall Function

Check should be a good result if the repair is completed.

•

When measuring ECM signals with a circuit tester, never allow

the two tester probes to contact.

Accidental contact of probes will cause a short circuit and

damage the ECM power transistor.

•

Never use ECM ground terminals when measuring input/out-

put voltage. Doing so may result in damage to the ECM's tran-

sistor. Use a ground other than ECM terminals, such as the

ground.

•

B1 indicates bank 1, B2 indicates bank 2 as shown in the fig-

ure.

SEF217U

SEF348N

PBIB1144E

2010 Pathfinder

PRECAUTIONS

EC-955

< PRECAUTION >

[VK56DE]

C

D

E

F

G

H

I

J

K

L

M

A

EC

N

P

O

•

Never operate fuel pump when there is no fuel in lines.

•

Tighten fuel hose clamps to the specified torque.

•

Never depress accelerator pedal when starting.

•

Immediately after starting, do not rev up engine unnecessar-

ily.

•

Never rev up engine just prior to shutdown.

•

When installing C.B. ham radio or a mobile phone, always

observe the following as it may adversely affect electronic

control systems depending on installation location.

-

Keep the antenna as far as possible from the electronic con-

trol units.

-

Keep the antenna feeder line more than 20 cm (8 in) away

from the harness of electronic controls.

Never let them run parallel for a long distance.

-

Adjust the antenna and feeder line so that the standing-wave

radio can be kept smaller.

-

Always ground the radio to vehicle body.

BBIA0529E

SEF709Y

SEF708Y

2010 Pathfinder
