EC-270 < COMPONENT DIAGNOSIS > [VQ40DE] P0455 EVAP CONTROL SYSTEM With CONSULT-III>>GO TO 9. 9. CHECK FOR EVAP LEAK With CONSULT-III 1. Turn ignition switch ON. 2. Select “EVAP SYSTEM CLOSE” of “WORK SUPPORT” mode with CONSULT-III. 3. Touch “START” and apply pressure into the EVAP line until the pressure indicator reaches the middle of CAUTION: • Never use compressed air or a high pressure pump. 2 , 0.6 psi) of pressure in the system. 4. Using EVAP leak detector, locate the EVAP leak. For the leak . OK or NG OK >> GO TO 11. NG >> Repair or replace. 10. CHECK FOR EVAP LEAK Without CONSULT-III 1. Turn ignition switch OFF. 2. Apply 12 volts DC to EVAP canister vent control valve (3). The - Fuel filler pipe (top of frame view) (1) - EVAP control system pressure sensor (2) - EVAP canister (4) - Drain filter (5) - : Vehicle front 3. Pressurize the EVAP line using pressure pump with 1.38 to 2.76 2 , 0.29 to 0.4 psi), then remove pump and EVAP service port adapter. CAUTION: • Never use compressed air or a high pressure pump. 2 , 0.6 psi) of pressure in the system. SEF916U SEF200U AWBIA0134ZZ 2009 Pathfinder |
