DLN-312 < SERVICE DATA AND SPECIFICATIONS (SDS) [PROPELLER SHAFT: 2F1310] SERVICE DATA AND SPECIFICATIONS (SDS) SERVICE DATA AND SPECIFICATIONS (SDS) SERVICE DATA AND SPECIFICATIONS (SDS) General Specification INFOID:0000000001297248 Unit: mm (in) Propeller Shaft Runout Unit: mm (in) Propeller Shaft Joint Flex Effort Unit: N·m (kg-m, in) Journal Axial Play Unit: mm (in) Snap Ring INFOID:0000000001297249 Model 2F1310 (4WD) Unit: mm (in) *Always check with the Parts Department for the latest parts information. Applied model 4WD VQ40DE VK56DE A/T Propeller shaft model 2F1310 Number of joints 2 Coupling method with front final drive Flange type Coupling method with transfer Flange type Shaft length (Spider to spider) 696 mm (27.40 in) Shaft outer diameter 63 5 mm (2.5 in) Item Limit Propeller shaft runout 0.6 mm (0.024 in) Item Limit Propeller shaft joint flex effort 1.96 N·m (0.20 kg-m, 17 in-lb) or less Item Limit Journal axial play 0.02 mm (0.0008 in) or less Thickness Color Part Number* 1.99 (0.0783) White 37146-C9400 2.02 (0.0795) Yellow 37147-C9400 2.05 (0.0807) Red 37148-C9400 2.08 (0.0819) Green 37149-C9400 2.11 (0.0831) Blue 37150-C9400 2.14 (0.0843) Light brown 37151-C9400 2.17 (0.0854) Black 37152-C9400 2.20 (0.0866) No paint 37153-C9400 |
