Nissan Pathfinder (2008 year). Manual - part 70

AV-400

< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

AV CONTROL UNIT

DTC Index

INFOID:0000000001450654

Self-diagnosis results display item

ALNIA0623GB

AV

AV CONTROL UNIT

AV-401

< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

Error item

Refer to

CAN COMM CIRCUIT [U1000]

AV-309, "DTC Logic"

CONTROL UNIT (CAN) [U1010]

AV-310, "DTC Logic"

Control Unit FLASH-ROM [U1200]

AV-311, "DTC Logic"

Gyro NO CONN [U1201]

AV-312, "DTC Logic"

CAN CONT [U1216]

AV-317, "DTC Logic"

BLUETOOTH CONN [U1217]

AV-318, "DTC Logic"

HDD CONN [U1218]

AV-319, "DTC Logic"

HDD READ [U1219]

AV-320, "DTC Logic"

XM SERIAL COMM [U1220]

AV-321, "DTC Logic"

HDD WRITE [U121A]

AV-322, "DTC Logic"

HDD COMM [U121B]

AV-323, "DTC Logic"

HDD ACCESS [U121C]

AV-324, "DTC Logic"

DSP CONN [U121D]

AV-325, "DTC Logic"

DSP COMM [U121E]

AV-326, "DTC Logic"

INTERNAL COMM [U121F]

AV-327, "DTC Logic"

GPS COMM [U1204]

AV-313, "DTC Logic"

GPS ROM [U1205]

AV-314, "DTC Logic"

GPS RAM [U1206]

AV-315, "DTC Logic"

GPS RTC [U1207]

AV-316, "DTC Logic"

FRONT DISP CONN [U1243]

AV-328, "DTC Logic"

GPS ANTENNA CONN [U1244]

AV-330, "DTC Logic"

CAMERA CONT. CONN [U1250]

AV-331, "DTC Logic"

XM ANTENNA CONN [U1258]

AV-333, "DTC Logic"

AV COMM CIRUICT [U1300]

AV-334, "Description"

CONTROL UNIT (AV) [U1310]

AV-335, "DTC Logic"

AV-402

< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

DISPLAY UNIT

DISPLAY UNIT

Reference Value

INFOID:0000000001450655

TERMINAL LAYOUT

PHYSICAL VALUES

JPNIA0006ZZ

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

1

(B)

Ground

Ground

—

Ignition

switch

ON

—

0V

2

(Y)

Ground

Battery power

Input

—

—

12V

3

(V)

Ground

ACC power

Input

Ignition

switch

ACC

—

12V

4

(W)

Ground

DVD video (-)

—

Ignition

switch

ON

When DVD mode is select-

ed

0V

5

—

Shield

—

—

—

—

6

(B)

Ground

RGB signal (G: green)

Input

Ignition

switch

ON

Start confirmation/adjust-
ment mode, and then dis-
play color bar by
selecting“Color Spectrum
Bar” on DISPLAY DIAGNO-
SIS screen.

7

—

RGB ground

—

—

—

—

8

(B)

Ground

Horizontal synchronizing
(HP) signal

Output

Ignition

switch

ON

—

SKIB2236J

SKIB3601E

AV

DISPLAY UNIT

AV-403

< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

9

(G)

Ground

RGB area (YS) signal

Input

Ignition

switch

ON

At RGB image displayed

5V

At rear view camera image
displayed

11

(V)

Ground

Communication signal
(CONT

→

DISP)

Input

Ignition

switch

ON

When adjusting display-
brightness

12

(W)

14

Rear view camera video (+)

Input

Ignition

switch

ON

Transmission in reverse

13

(B)

Ground

Ground

—

Ignition

switch

ON

—

0V

14

Ground

Rear view camera video (-)

—

Ignition

switch

ON

Transmission in reverse

0V

15

(O)

4

(W)

DVD video (+)

Input

Ignition

switch

ON

When DVD mode is select-
ed

17

(L)

Ground

RGB signal (R: red)

Input

Ignition

switch

ON

Start confirmation/adjust-
ment mode, and then dis-
play color bar by selecting
“Color Spectrum Bar” on
DISPLAY DIAGNOSIS
screen.

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

PKIB4948J

PKIB5039J

SKIB2251J

SKIB2251J

SKIB2238J

AV-404

< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

DISPLAY UNIT

18

(Y)

Ground

RGB signal (B: blue)

Input

Ignition

switch

ON

Start confirmation/adjust-
ment mode, and then dis-
play color bar by
selecting“Color Spectrum
Bar” on DISPLAY DIAGNO-
SIS screen.

19

(R)

Ground

RGB synchronizing signal

Input

Ignition

switch

ON

—

20

(W)

Ground

Vertical synchronizing (VP)
signal

Output

Ignition

switch

On

—

21

—

RGB synchronizing ground

—

—

—

—

22

(LG)

Ground

Communication signal
(DISP

→

CONT)

Output

Ignition

switch

ON

When adjusting display-
brightness

23

—

Shield

—

—

—

—

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB2237J

SKIB3603E

SKIB3598E

PKIB5039J

AV

BOSE SPEAKER AMP

AV-405

< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

BOSE SPEAKER AMP

Reference Value

INFOID:0000000001507379

TERMINAL LAYOUT

PHYSICAL VALUES

AWNIA0147ZZ

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

1

(Y)

Ground

Battery power

Input

—

—

12V

9

(B)

10

(G)

Audio signal rear door
speaker and tweeter LH

Output

Ignition

switch

ON

Audio output

11

(GR)

12

(O)

Audio signal rear door
speaker and tweeter RH

Output

Ignition

switch

ON

Audio output

13

(LG)

14

(L)

Audio signal front door
speaker and tweeter LH

Output

Ignition

switch

ON

Audio output

15

(W)

16

(R)

Audio signal front door
speaker and tweeter RH

Output

Ignition

switch

ON

Audio output

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

AV-406

< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

BOSE SPEAKER AMP

17

(B)

Ground

Ground

—

Ignition

switch

ON

—

0V

19

(SB)

3

(B)

Audio signal subwoofer

Output

Ignition

switch

ON

Audio output

22

(Y)

Ground

Subwoofer amp. ON signal

Output

Ignition

switch

ACC

Audio output

12V

24

(R)

23

(B)

Audio signal rear RH

Input

Ignition

switch

ON

Audio input

26

(L)

25

(Y)

Audio signal rear LH

Input

Ignition

switch

ON

Audio input

28

(G)

27

(W)

Audio signal front RH

Input

Ignition

switch

ON

Audio input

30

(R)

29

(B)

Audio signal front LH

Input

Ignition

switch

ON

Audio input

31

(SB)

Ground

Amp. ON signal

Input

Ignition

switch

ON

Audio output

12V

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

AV

REAR VIEW CAMERA CONTROL UNIT

AV-407

< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

REAR VIEW CAMERA CONTROL UNIT

Reference Value

INFOID:0000000001470311

TERMINAL LAYOUT

PHYSICAL VALUES

WKIA5224E

Terminal

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

1

 (R/B)

Ground

Battery power

Input

Ignition

switch

OFF

—

Battery voltage

2

(G/R)

Ground

ACC power

Input

Ignition

switch

ACC

—

Battery voltage

3

(B)

Ground

Ground

—

Ignition

switch

ON

—

0V

4

(LG)

Ground

Reverse signal input

Input

Ignition

switch

ON

A/T selector lever R
position

Battery voltage

A/T selector lever in
other than R position

0V

5

(BR)

Ground

AV Control

Output

Ignition

switch

ON

—

0V

6

(W)

Ground

DDL

Output

—

—

—

8

(Y)

Ground

Camera power output

Output

Ignition

switch

ON

A/T selector lever R
position

6V

9

Ground

Camera image input (–)

Input

Ignition

switch

ON

—

0V

10

(G)

Ground

Camera image input (+)

Input

Ignition

switch

ON

A/T selector lever R
position

SKIA4894E
