DTC P0122, P0123 TP SENSOR EC-219 C D E F G H I J K L M A EC 2007 Pathfinder Component Inspection UBS00K6A THROTTLE POSITION SENSOR 1. Reconnect all harness connectors disconnected. 2. Perform EC-77, "Throttle Valve Closed Position Learning" . 3. Turn ignition switch ON. 4. Set selector lever to D position. 5. Check voltage between ECM terminals 50 (TP sensor 1 signal), 6. If NG, replace electric throttle control actuator and go to the next 7. Perform EC-77, "Throttle Valve Closed Position Learning" . 8. Perform EC-77, "Idle Air Volume Learning" . Removal and Installation UBS00K6B ELECTRIC THROTTLE CONTROL ACTUATOR Refer to EM-17, "INTAKE MANIFOLD COLLECTOR" . Terminal Accelerator pedal Voltage 50 Fully released More than 0.36V Fully depressed Less than 4.75V 69 Fully released Less than 4.75V Fully depressed More than 0.36V PBIB1608E |
