TROUBLE DIAGNOSIS FOR SELF-DIAGNOSTIC ITEMS BRC-109 [HDC/HSA/VDC/TCS/ABS] C D E G H I J K L M A B BRC 2007 Pathfinder 3. CHECKING ABS MOTOR AND MOTOR RELAY POWER SYSTEM 1. Check voltage between ABS actuator and electric unit (control 2. Check resistance between ABS actuator and electric unit (con- OK or NG OK >> Perform self-diagnosis again. If the same results appear, replace ABS actuator and electric unit (control BRC-130, "Removal and Installation" NG >> Repair the circuit. Stop Lamp Switch System Inspection EFS00670 INSPECTION PROCEDURE 1. SELF-DIAGNOSIS RESULT CHECK Check self-diagnosis results. Is the above displayed in the self-diagnosis display items? YES >> GO TO 2. NO >> Inspection End. 2. CONNECTOR INSPECTION 1. Disconnect the ABS actuator and electric unit (control unit) connector E125 and stop lamp switch connec- 2. Check the terminals for deformation, disconnection, looseness or damage. OK or NG OK >> GO TO 3. NG >> Repair or replace as necessary. ABS actuator and electric unit (control unit) harness connector E125 Body ground Measured value (Approx.) 1 — 12V WFIA0209E ABS actuator and electric unit (control unit) connector E125 Body ground Measured value (Approx.) 16 — 0 Ω 47 — WFIA0196E Self-diagnosis results STOP LAMP SW |
