HEADLAMP (FOR USA) LT-19 C D E F G H I J L M A B LT 2006 Pathfinder 5. CHECK HEADLAMP CIRCUIT 1. Turn ignition switch OFF. 2. Disconnect IPDM E/R connector. 3. Check continuity between IPDM E/R harness connector E123 4. Check continuity between IPDM E/R harness connector E123 OK or NG OK >> Replace IPDM E/R. Refer to PG-32, "Removal and Installation of IPDM E/R" NG >> Repair harness or connector. 6. CHECK HEADLAMP GROUND 1. Turn ignition switch OFF. 2. Check continuity between front headlamp RH harness connec- 3. Check continuity between front headlamp LH harness connector OK or NG OK >> Check front headlamp connector for damage or poor connection. Repair as necessary. NG >> Repair harness or connector. Headlamp HI Does Not Illuminate (One Side) EKS00FUB 1. BULB INSPECTION Inspect inoperative headlamp bulb. OK or NG OK >> GO TO 2. NG >> Replace headlamp bulb. Refer to 56 - 1 : Continuity should exist. 55 - 1 : Continuity should exist. WKIA3498E 2 - Ground : Continuity should exist. 2 - Ground : Continuity should exist. WKIA3499E |
