SIDE WINDOW GLASS GW-65 C D E F G H J K L M A B GW 2006 Pathfinder REMOVAL 1. Remove the luggage side upper finisher. Refer to . a. Disconnect the antenna. b. If the window glass is to be reused, mark the body and the glass with mating marks. c. Remove the glass using piano wire or power cutting tool and an inflatable pump bag. WARNING: When cutting the glass from the vehicle, always wear safety glasses and heavy gloves to help prevent CAUTION: ● When the side window glass is to be reused, do not use a cutting knife or power cutting tool. ● Be careful not to scratch the glass when removing. ● Do not set or stand the glass on its edge. Small chips may develop into cracks. INSTALLATION ● Use a genuine NISSAN Urethane Adhesive Kit (if available) or equivalent and follow the instructions fur- ● While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced ● Check gap along bottom to confirm that glass does not contact sheet metal. ● Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely ● Install parts removed. WARNING: ● Keep heat and open flames away as primers and adhesive are flammable. ● The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid ● Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if ● Driving the vehicle before the urethane adhesive has completely cured may affect the perfor- CAUTION: ● Do not use an adhesive which is past its usable term. Shelf life of this product is limited to six ● Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator. ● Do not leave primers or adhesive cartridge unattended with their caps open or off. ● The vehicle should not be driven for at least 24 hours or until the urethane adhesive has com- Repairing Water Leaks for Side Window Glass Leaks can be repaired without removing or reinstalling glass. 1. Glass 2. Primer area 3. Body side outer 4. Rear door assembly 5. Back door assembly 6. Locating clips 7. Urethane a. 15 mm (0.59 in) b. 42.5 mm (1.67 in) c. 3.0 mm (0.12 in) d. 2.5 mm (0.1 in) e. 12 mm (0.47 in) f. 7.0 mm (0.28 in) g. 11.5 mm (0.45 in) h. 3.3 mm (0.13 in) j. 30 mm (1.2 in) |
