SERVICE DATA AND SPECIFICATIONS (SDS) EC-675 C D E F G H I J K L M A EC 2006 Pathfinder SERVICE DATA AND SPECIFICATIONS (SDS) PFP:00030 Fuel Pressure UBS00KIZ Idle Speed and Ignition Timing UBS00KJ0 *: Under the following conditions: ● Air conditioner switch: OFF ● Electric load: OFF (Lights, heater fan & rear window defogger) ● Steering wheel: Kept in straight-ahead position Calculated Load Value UBS00KJ1 Mass Air Flow Sensor UBS00KJ2 *: Engine is warmed up to normal operating temperature and running under no load. Intake Air Temperature Sensor UBS00KJ3 Engine Coolant Temperature Sensor UBS00KJ4 Air Fuel Ratio (A/F) Sensor 1 Heater UBS00KJ5 Heated Oxygen sensor 2 Heater UBS00KJ6 Crankshaft Position Sensor (POS) UBS00KJ7 Refer to EC-365, "Component Inspection" Camshaft Position Sensor (PHASE) UBS00KJ8 Refer to EC-374, "Component Inspection" Throttle Control Motor UBS00KJ9 Fuel pressure at idling kPa (kg/cm 2 , psi) Approximately 350 (3.57, 51) Target idle speed No load* (in P or N position) 625 ± 50 rpm Air conditioner: ON In P or N position 775 rpm or more Ignition timing In P or N position 15 ± 5 ° BTDC Condition Calculated load value% (Using CONSULT-II or GST) At idle 5 - 35 At 2,500 rpm 5 - 35 Supply voltage Battery voltage (11 - 14V) Output voltage at idle 0.9 - 1.2*V Mass air flow (Using CONSULT-II or GST) 2.0 - 6.0 g·m/sec at idle* 7.0 - 20.0 g·m/sec at 2,500 rpm* Temperature ° C ( ° F) Resistance k Ω 25 (77) 1.800 - 2.200 Temperature ° C ( ° F) Resistance k Ω 20 (68) 2.1 - 2.9 50 (122) 0.68 - 1.00 90 (194) 0.236 - 0.260 Resistance [at 25 ° C (77 ° F)] 2.3 - 4.3 Ω Resistance [at 25 ° C (77 ° F)] 9.9 - 13.3 Ω Resistance [at 25 ° C (77 ° F)] Approximately 1 - 15 Ω |
